Tractor · 1994Unverified
Mahindra 575
Mahindra 575 — Utility tractor · 42 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
42 hp
Weight
1876 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Built in Maharashtra, IndiaReference
Two-wheel driveReference
Steeringhydrostatic powerReference
Disc brakesReference
Open operator station.Reference
Engine
Mahindra 2.5L 4-cyl dieselReference
Engine33.6 kWReference
Mahindra MDI 2500Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke89 x 102 mmReference
Power33.6 kWReference
Air cleanerdryReference
Compression18:1Reference
Rated RPM2300Reference
Idle RPM750-2500Reference
Firing order1-3-4-2Reference
StarterelectricReference
Starter volts12Reference
Oil capacity7.5 LReference
Coolant capacity11.0 LReference
Intake valve clearance0.305 mmReference
Intake valve clearance0.406 mmReference
Exhaust valve clearance0.406 mmReference
Exhaust valve clearance0.508 mmReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch279.4mm dry discReference
Oil capacity18.0 LReference
Four gears (1-4) plus reverse (R) in high and low ranges.Reference
PTO & Hydraulics
PTO (claimed)31.6 kWReference
Hydraulic system11.0 LReference
Typeopen centerReference
Capacity11.0 LReference
Pump flow31.2 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift997 kgReference
Rear PTOliveReference
Clutch228.6mm dry discReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2059Reference
Engine RPM1000@2227Reference
Capacities
Fuel35.0 LReference
Dimensions
Wheelbase194 cmReference
Weight1876 kgReference
Front tire6.50x20Reference
Rear tire16.9x28Reference
Ag front6.50x20Reference
Ag rear16.9x28Reference
Length325 cmReference
Width198 cmReference
Height (steering wheel)182 cmReference
Operating weight1876 kgReference
Ground clearance25 cmReference
Front tread129 to 170 cmReference
Rear tread132 to 182 cmReference
Electrical
GroundnegativeReference
Charging amps11Reference
Battery volts12Reference
Battery AH88Reference
Speeds
16.9x28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
