Tractor · 1994Unverified

Mahindra 575

Name: Mahindra 575
Brand: Mahindra

Mahindra 575 — Utility tractor · 42 hp. Reference specifications; pending source verification.

The Mahindra 575 is a compact tractor model with a rated output of 42 hp. It was manufactured in 1994. The tractor features a 4-cylinder diesel liquid-cooled engine and a hydrostatic transmission for two-wheel drive. Its listed weight is 1876 kg, and it is suited to tasks involving approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

42 hp

Weight

1876 kg

Catalogue coverage

Variants represented

Richest spec table

67 rows

Recorded power

42 hp

Recorded weight

1876 kg

Transmissions

8-speed gear

Production years

1994-1994

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Built in Maharashtra, IndiaReference

Two-wheel driveReference

Steeringhydrostatic powerReference

Disc brakesReference

Open operator station.Reference

Engine

Mahindra 2.5L 4-cyl dieselReference

Engine33.6 kWReference

Mahindra MDI 2500Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke89 x 102 mmReference

Power33.6 kWReference

Air cleanerdryReference

Compression18:1Reference

Rated RPM2300Reference

Idle RPM750-2500Reference

Firing order1-3-4-2Reference

StarterelectricReference

Starter volts12Reference

Oil capacity7.5 LReference

Coolant capacity11.0 LReference

Intake valve clearance0.305 mmReference

Intake valve clearance0.406 mmReference

Exhaust valve clearance0.406 mmReference

Exhaust valve clearance0.508 mmReference

Transmission

8-speed gearReference

TypegearReference

Gears8 forward and 2 reverseReference

Clutch279.4mm dry discReference

Oil capacity18.0 LReference

Four gears (1-4) plus reverse (R) in high and low ranges.Reference

PTO & Hydraulics

PTO (claimed)31.6 kWReference

Hydraulic system11.0 LReference

Typeopen centerReference

Capacity11.0 LReference

Pump flow31.2 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift997 kgReference

Rear PTOliveReference

Clutch228.6mm dry discReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2059Reference

Engine RPM1000@2227Reference

Capacities

Fuel35.0 LReference

Dimensions

Wheelbase194 cmReference

Weight1876 kgReference

Front tire6.50x20Reference

Rear tire16.9x28Reference

Ag front6.50x20Reference

Ag rear16.9x28Reference

Length325 cmReference

Width198 cmReference

Height (steering wheel)182 cmReference

Operating weight1876 kgReference

Ground clearance25 cmReference

Front tread129 to 170 cmReference

Rear tread132 to 182 cmReference

Electrical

GroundnegativeReference

Charging amps11Reference

Battery volts12Reference

Battery AH88Reference

Speeds

16.9x28 rear tires.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
