Tractor · 2002Unverified

Mahindra 6500

Name: Mahindra 6500
Brand: Mahindra

Mahindra 6500 — 00 Series · 57 hp. Reference specifications; pending source verification.

The Mahindra 6500 is a compact tractor with a rated output of 57 hp, produced from 2002 to 2008. It features a 4-cylinder diesel liquid-cooled engine, coupled with a four-wheel drive system and an 8-speed gearbox. The tractor weighs between 4966 and 6280 pounds. It is designed to handle tasks on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

57 hp

Weight

4966 to 6280 pounds

Catalogue coverage

Variants represented

Richest spec table

65 rows

Recorded power

57 hp

Recorded weight

2252 kg

Transmissions

8-speed

Production years

2002-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Built in Maharashtra, IndiaReference

Two- or four-wheel driveReference

Power steeringReference

2WD Brakesdry discReference

4WD Brakeswet discReference

Two-post folding ROPS.Reference

Engine

Mahindra 3.5L 4-cyl dieselReference

Engine44.0 kWReference

Mahindra NE465Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.5 LReference

Bore/Stroke96 x 122 mmReference

Power44.0 kWReference

Fuel systemdirect injectionReference

Compression19.4:1Reference

Rated RPM2200Reference

Starter volts12Reference

Transmission

8-speedReference

Transmissionconstant meshReference

Gears8 forward and 2 reverseReference

The 8/2 transmission was used the two-wheel drive version of the Mahindra 6500.Reference

Transmissionsynchomesh shuttleReference

Gears8 forward and reverseReference

The 8-speed shuttle was used on the 6500 with four-wheel drive.Reference

PTO & Hydraulics

PTO (claimed)42.5 kWReference

Typeopen centerReference

Valves2Reference

Pump flow41.6 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift1799 kgReference

2WD Rear PTOliveReference

4WD Rear PTOindependentReference

2WD Rear PTO Type540Reference

4WD Rear PTO Type540/1000Reference

Dimensions

Weight4966 to 6280 poundsReference

Front tire9.5Lx15Reference

2WD Rear tire16.9x28Reference

2WD Standard tires (ag)Front: 9.5Lx15. Rear: 16.9x28Reference

4WD Standard tires (ag)Front: 11.2x24. Rear: 16.9x30Reference

2WD Lawn/turf front27x12LL-15Reference

4WD Lawn/turf frontLSW305x521Reference

Lawn/turf rearLSW570x648Reference

2WD Industrial front11Lx15Reference

4WD Industrial front12.5/80x18Reference

Industrial rear19.5Lx24Reference

2WD Length347 cmReference

4WD Length381 cmReference

Width196 cmReference

2WD Weight2252 kgReference

4WD Weight2848 kgReference

Mahindra 6500 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps36Reference

Charging volts12Reference

Battery volts12Reference

Battery AH96Reference

Attachment overview

Mahindra ML260 loaderReference

Mahindra ML264 loaderReference

Mahindra ML265 loaderReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
