Tractor · 2004Unverified

Mahindra 6520

Name: Mahindra 6520
Brand: Mahindra

Mahindra 6520 — 20 Series · 55 hp. Reference specifications; pending source verification.

The Mahindra 6520 is a tractor model rated at approximately 55 hp, categorising it at the lighter end of its class. Produced from 2004 to 2008, this model is equipped with a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 12-speed gearbox. The operating weight of the 6520 ranges from 7100 to 7300 pounds, and it is suitable for operations on up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

55 hp

Weight

7100 to 7300 pounds

Catalogue coverage

Variants represented

Richest spec table

53 rows

Recorded power

55 hp

Recorded weight

3220 kg

Transmissions

12-speed synch shuttle

Production years

2004-2008

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Built in Maharashtra, IndiaReference

Original price$21,970 (2008 2WD )Reference

Original price$26,780 (2008 4WD )Reference

Two- or four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

Mahindra 3.2L 4-cyl dieselReference

Engine48.5 kWReference

Mahindra NE462Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement3.2 LReference

Power48.5 kWReference

Fuel systemdirect injectionReference

Compression19.4:1Reference

Rated RPM2300Reference

Starter volts12Reference

Transmission

12-speed synch shuttleReference

Typesynch shuttleReference

Gears12 forward and reverseReference

Clutchdual dry with creametallic liningReference

PTO & Hydraulics

PTO (claimed)41.0 kWReference

Typeopen centerReference

Valves1Reference

Pump flow43.1 lpmReference

Steering flow18.9 lpmReference

Rear TypeIIReference

Controlposition and draft controlReference

Rear lift2313 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Engine RPM540@2187Reference

Dimensions

Weight7100 to 7300 poundsReference

Front tire9.5Lx15Reference

2WD Rear tire16.9x28Reference

2WD Standard tires (ag)Front: 9.5Lx15. Rear: 16.9x28Reference

4WD Standard tires (ag)Front: 9.5x24. Rear: 16.9x28Reference

Industrial front12.5/80x18 (4WD)Reference

Industrial rear19.5Lx24 (4WD)Reference

Length400 cmReference

Width196 cmReference

2WD Weight3220 kgReference

4WD Weight3311 kgReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Charging volts12Reference

Battery CCA925Reference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
