Tractor · 2008Unverified

Mahindra 6530

Mahindra 6530 — 30 Series · 57 hp. Reference specifications; pending source verification.

The Mahindra 6530 is a tractor with a rated power of 57 horsepower, situated at the lighter end of its class. This model was manufactured in 2008. It features a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, coupled with mechanical front-wheel drive and a hydrostatic transmission. The operating weight of the Mahindra 6530 ranges from 5557 to 6302 pounds.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
57 hp
Max power
65 hp
Weight
5557 to 6302 pounds

Catalogue coverage

Variants represented
2
Richest spec table
116 rows
Recorded power
57 hp
Recorded weight
646 kg
Transmissions
8-speed synchronized shuttle
Production years
2008-2008
Verified variants
0

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference
Utility tractorReference
Original price$27,975 (2013 4WD )Reference
Original price$22,220 (2013 2WD )Reference
Drive4x2 2WDReference
Drive4x4 MFWD 4WD (optional)Reference
Steeringhydrostatic powerReference
Wet disc brakesReference
Two-post foldable ROPS.Reference

Engine

Mahindra 2.5L 3-cyl dieselReference
Fuel tank64.7 LReference
Engine48.5 kWReference
MahindraReference
turbocharged intercooled dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Power48.5 kWReference
Fuel systemdirect injectionReference
Compression17.2:1Reference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Fuel TypedieselReference
No of Cylinders3 cylinderReference
Rated engine speed2,200 RPMReference
Compression ratio17.2:1Reference
Cooling systemliquid-cooledReference

Transmission

8-speed synchronized shuttleReference
8-speed synchromeshReference
Typesynchronized shuttleReference
Gears8 forward and reverseReference
Clutchcerametallic dry discReference
TypesynchromeshReference
Full synchromesh transmission used on the 6530 with 4WD.Reference
Transmission TypeSync ShuttleReference
forward and reverse optionsSynchronized Shuttle : 8 F and 8 R | Synchromesh: 8 F and 8 RReference
Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)42.5 kWReference
Typeopen centerReference
Valves2Reference
Pump flow40.9 lpmReference
Steering flow18.0 lpmReference
Rear Type1/2Reference
Controlposition and draft controlReference
Rear lift1799 kgReference
Rear PTOindependentReference
Rear PTO Type540Reference
Engine RPM540@2059Reference

Dimensions

Weight5557 to 6302 poundsReference
Front tire9.5x15Reference
Rear tire16.9x28 (2WD)Reference
Weight646 kgReference
Weight723 kgReference
Standard tires (ag)Front: 9.5x15. Rear: 16.9x28 (2WD)Reference
Standard tires (ag)Front: 11.2x24. Rear: 16.9x30 (4WD)Reference
Industrial front12.5/80x18Reference
Industrial rear19.5Lx24Reference
2WD Length350 cmReference
4WD Length368 cmReference
4WD Width196 cmReference
4WD Width205 cmReference
2WD ROPS Operating weight2520 kgReference
4WD ROPS Operating weight2858 kgReference

Mahindra 6530 attachments

front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps55Reference
Batteries12Reference
Battery volts12Reference
Battery AH96Reference
Battery size96 AHReference

Attachment overview

Mahindra ML262 loaderReference
Mahindra ML266 loaderReference
BackhoeReference

Mahindra 509 Backhoe

Backhoe typeMahindra 509 BackhoeReference
Digging depth294 cmReference
2-Foot flat digging depth292 cmReference
8-Foot flat digging depth251 cmReference
Reach from pivot388 cmReference
Loading height208 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force1249 kgReference

Mahindra 511 Backhoe

Backhoe typeMahindra 511 BackhoeReference
Digging depth337 cmReference
2-Foot flat digging depth335 cmReference
8-Foot flat digging depth302 cmReference
Reach from pivot439 cmReference
Loading height243 cmReference
Bucket Rotation180°Reference
Swing Arc180°Reference
Bucket force2574 kgReference
Dipperstick force1386 kgReference

General

Make & ModelMahindraReference
Rollover protective structureTwo-post foldable ROPS.Reference

Capacities

Capacity152.4 ciReference

Power

Max Power65 hpReference

PTO

PTO Power57 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM540 RPMReference
Engine Speed on Rear PTO speed540@2,059 RPMReference

Steering & brakes

Brakeswet discReference
Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference
Remote Valves2 ValvesReference
Steering & Implements flow4.75 gpm (10.8 gpm)Reference
Rear Hitch category (SAE designation)Category 1/2Reference
Rear Hitch maximum lift capacity1,799.9 kgReference
Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Overall Length368.3 cmReference
Overall Width205.7 cmReference
Overall weight2,858.5 kgReference

Operator station

Seat SuspensionTrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
