Tractor · 2011Unverified

Mahindra 7060

Name: Mahindra 7060
Brand: Mahindra

Mahindra 7060 — 60 Series · 57 hp. Reference specifications; pending source verification.

The Mahindra 7060 is a compact tractor model with a rated output of 57 hp. It was produced in 2011. The 7060 features a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, which drives a four-wheel drive system via a hydrostatic transmission. Its weight is listed as 6727 to 7551 pounds, and it is suitable for tasks covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

57 hp

Max power

67 hp

Weight

6727 to 7551 pounds

Catalogue coverage

Variants represented

Richest spec table

114 rows

Recorded power

57 hp

Recorded weight

646 kg

Transmissions

12-speed synchromesh

Production years

2011-2011

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

ManufacturerMahindraReference

Utility tractorReference

Original price$30,810 (2013 ROPS )Reference

Original price$42,690 (2013 ROPS )Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS. Cab optional with air-conditioning.Reference

Engine

Mahindra 2.5L 3-cyl dieselReference

Fuel tank73.1 LReference

Engine50.0 kWReference

MahindraReference

turbocharged intercooled dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Power50.0 kWReference

Fuel systemdirect injectionReference

Compression17.2:1Reference

Rated RPM2200Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,200 RPMReference

Compression ratio17.2:1Reference

Cooling systemliquid-cooledReference

Transmission

12-speed synchromeshReference

TypesynchromeshReference

Gears12 forward and reverseReference

Clutchcerametallic dry discReference

Transmission TypeSync ShuttleReference

forward and reverse optionsSynchromesh: 12 F and 12 RReference

Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)42.5 kWReference

Typeopen centerReference

Valves2Reference

Pump flow41.6 lpmReference

Steering flow19.3 lpmReference

Rear Type2Reference

Controlposition and draft controlReference

Rear lift2313 kgReference

Rear PTOindependentReference

Rear PTO Type540Reference

Engine RPM540@2186Reference

Dimensions

Weight6727 to 7551 poundsReference

Front tire9.5x24Reference

Rear tire16.9x28Reference

Weight646 kgReference

Weight723 kgReference

Standard tires (ag)Front: 9.5x24. Rear: 16.9x28Reference

Industrial front12.5/80x18Reference

Industrial rear18.5Lx24Reference

Length400 cmReference

Width196 cmReference

Height (cab)272 cmReference

ROPS Operating weight3051 kgReference

Cab Operating weight3425 kgReference

Mahindra 7060 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

ROPS Charging amps55Reference

Cab Charging amps120Reference

Batteries12Reference

Battery volts12Reference

Battery AH96Reference

Battery size96 AHReference

Attachment overview

Front-end loaderReference

BackhoeReference

The ML272 loader was compatible with ROPS models, while the ML274 loader was compatible on the 5010 with a cab. Both loaders had the same ratings.Reference

Mahindra 509 Backhoe

Backhoe typeMahindra 509 BackhoeReference

Digging depth294 cmReference

2-Foot flat digging depth292 cmReference

8-Foot flat digging depth251 cmReference

Reach from pivot388 cmReference

Loading height208 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force2574 kgReference

Dipperstick force1249 kgReference

Mahindra 511 Backhoe

Backhoe typeMahindra 511 BackhoeReference

Digging depth337 cmReference

2-Foot flat digging depth335 cmReference

8-Foot flat digging depth302 cmReference

Reach from pivot439 cmReference

Loading height243 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force2574 kgReference

Dipperstick force1386 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post foldable ROPS.Reference

Capacities

Capacity152.4 ciReference

Power

Max Power67 hpReference

PTO

PTO Power57 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Engine Speed on Rear PTO speed540@2,186 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves2 ValvesReference

Steering & Implements flow5.1 gpm (11 gpm)Reference

Rear Hitch category (SAE designation)Category 2Reference

Rear Hitch maximum lift capacity2,313.3 kgReference

Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Height Over Cab272.5 cmReference

Overall Length400.3 cmReference

Overall Width196.3 cmReference

Overall weight3,051.3 kgReference

Wheels & tyres

Rear Wheel TypeStandard tires (ag):Rear: 16.9x28 | Industrial rear: 18.5Lx24Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionTrueReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
