Tractor · 2018Unverified
Mahindra 9110
Mahindra 9110 — Utility tractor · 110 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
110 hp
Weight
4257 kg
Hover a source tag to verify
Overview
ManufacturerMahindraReference
Utility tractorReference
Original price$73,750 (2018 sync shuttle )Reference
Original price$79,320 (2018 power shuttle )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Cab standard with air-conditioning.Reference
Variants
9110Ssync shuttleReference
9110Ppower shuttleReference
Engine
Mahindra 3.5L 4-cyl dieselReference
Engine82.0 kWReference
MahindraReference
dieselReference
4-cylinderReference
liquid-cooled inlineReference
Displacement3.5 LReference
Bore/Stroke96 x 112 mmReference
EmissionsTier IVReference
Power82.0 kWReference
Rated RPM2300Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed sync shuttleReference
32-speed power shuttleReference
Typesync shuttleReference
Gears12 forward and reverseReference
Typepower shuttleReference
Gears32 forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Rear valves2 to 4Reference
Pump flow81.4 lpmReference
Steering flow35.0 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
S Rear lift2624 kgReference
P Rear lift3460 kgReference
Rear PTOindependentReference
S Rear PTO Type540/1000 (1.375)Reference
P Rear PTO Type540/750/1000 (1.375)Reference
Engine RPM540@2220Reference
Engine RPM750@2208Reference
Engine RPM1000@2227Reference
Dimensions
Weight4257 kgReference
Length430 cmReference
Width230 cmReference
Height (cab)271 cmReference
Mahindra 9110 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
