Tractor · 2017Unverified

Mahindra eMax 22S

Name: Mahindra eMax 22S
Brand: Mahindra

Mahindra eMax 22S — eMax S Series · 16 hp. Reference specifications; pending source verification.

The Mahindra eMax 22S is a compact tractor model with a rated output of 16 hp. It was manufactured from 2017 to 2019. The tractor features a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and four-wheel drive system. It is suitable for tasks on land areas of approximately 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

16 hp

Max power

22 hp

Catalogue coverage

Variants represented

Richest spec table

108 rows

Recorded power

16 hp

Transmissions

6-speed gear

Production years

2017-2019

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMahindraReference

ManufacturerTYMReference

Sub-Compact Utility tractorReference

Original price$12,670 (2018 gear )Reference

Original price$13,230 (2018 hydrostatic )Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Daedong 1.0L 3-cyl dieselReference

Fuel tank22.0 LReference

Engine16.4 kWReference

Daedong 3C100Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.0 LReference

Bore/Stroke75 x 76 mmReference

EmissionsTier IVReference

Power16.4 kWReference

Fuel systemindirect injectionReference

Compression21:1Reference

Rated RPM3000Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed3,000 RPMReference

Emissions complianceTier IVReference

Bore and stroke2.95x2.99 inchesReference

Compression ratio21:1Reference

Cooling systemliquid-cooledReference

Transmission

6-speed gearReference

hydrostaticReference

TypegearReference

Gears6 forward and 2 reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeGearReference

forward and reverse optionsGear:6 F and 2 R | Hydrostatic : Infinite F and R (2-range)Reference

Wheel Drive4WDReference

PTO & Hydraulics

Gear PTO (claimed)11.9 kWReference

Hydro PTO (claimed)11.1 kWReference

Typeopen centerReference

Rear valves1Reference

Pump flow17.0 lpmReference

Steering flow9.8 lpmReference

Rear TypeIReference

Rear lift598 kgReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@2893Reference

Mid PTO Type2000Reference

Engine RPM2000@2875Reference

Dimensions

Front tire6x12Reference

Rear tire9.5x16Reference

Standard tires (ag)Front: 6x12. Rear: 9.5x16Reference

Lawn/turf front20x8-10Reference

Lawn/turf rear29x12.5-15Reference

Industrial front20x8-10Reference

Industrial rear27x12.5-15Reference

Length255 cmReference

Width129 cmReference

Height (ROPS)227 cmReference

Mahindra eMax 22S attachments

60" mid-mount mower deckReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Battery AH50Reference

Battery size50 AHReference

Attachment overview

60" mid-mount mower deckReference

Front-end loaderReference

BackhoeReference

60" Mower deck

Typemid-mount Mahindra 25MReference

Type3-bladeReference

Cutting width152 cmReference

Mahindra eMax 26B Backhoe

Backhoe typeMahindra eMax 26B BackhoeReference

Digging depth193 cmReference

2-Foot flat digging depth190 cmReference

Reach from pivot259 cmReference

Loading height157 cmReference

Bucket Rotation180°Reference

Swing Arc150°Reference

Bucket force972 kgReference

Dipperstick force409 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post folding ROPS.Reference

Capacities

Capacity61.5 ciReference

Power

Max Power22 hpReference

PTO

PTO Power15.9 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Engine Speed on Rear PTO speed540@2,893 RPMReference

Engine Speed on Mid PTO speed2,000@2,875 RPMReference

Steering & brakes

BrakesWet disc brakesReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 ValvesReference

Steering & Implements flow2.6 gpm (4.5 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity598.7 kgReference

Dimensions & weight

Height Over ROPS227.8 cmReference

Overall Length255.3 cmReference

Overall Width129 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
