Mahindra Max 25XL
Mahindra Max 25XL — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
777 kg
Hover a source tag to verify
Overview
DistributorMahindraReference
ManufacturerMitsubishiReference
Compact Utility tractorReference
Built in JapanReference
Original price was $16,730 in 2019Reference
Four-wheel driveReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Mitsubishi 1.3L 3-cyl dieselReference
Fuel tank23.1 LReference
Engine17.9 kWReference
Mitsubishi S3L2Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.3 LReference
Bore/Stroke78 x 92 mmReference
Power17.9 kWReference
Fuel systemindirect injectionReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Transmission
hydrostaticReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
PTO (claimed)14.9 kWReference
Typeopen centerReference
Pump flow17.4 lpmReference
Total flow27.6 lpmReference
Rear TypeIReference
Rear lift614 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2376Reference
Mid PTO Type2000Reference
Engine RPM2000@2556Reference
Dimensions
Wheelbase147 cmReference
Weight777 kgReference
Front tire6x12Reference
Rear tire9.5x16Reference
Weight186 kgReference
Weight276 kgReference
Standard tires (ag)Front: 6x12. Rear: 9.5x16Reference
Lawn/turf front20x8-10Reference
Lawn/turf rear29x12.5-15Reference
Industrial front20x8-10Reference
Industrial rear27x12.5-15Reference
Length269 cmReference
Width128 cmReference
Height207 cmReference
Ground clearance18 cmReference
Mahindra Max 25XL attachments
60" mid-mount mower deckReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps50Reference
Battery CCA450Reference
Battery volts12Reference
Attachment overview
60" mid-mount mower deckReference
Front-end loaderReference
BackhoeReference
60" Mower deck
Typemid-mount MAhindra 62MReference
Type3-bladeReference
Cutting width152 cmReference
Cut height2 to 10 cmReference
Mahindra 26B Backhoe
Backhoe typeMahindra 26B BackhoeReference
Bucket width30 cmReference
Digging depth203 cmReference
2-Foot flat digging depth199 cmReference
Bucket force1029 kgReference
Dipperstick force566 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
