Tractor · 2014Unverified

Mahindra Max 26XL

Name: Mahindra Max 26XL
Brand: Mahindra

Mahindra Max 26XL — Max Series · 22 hp. Reference specifications; pending source verification.

The Mahindra Max 26XL is a compact tractor with a rated output of 22 hp, produced from 2014 to 2019. This model features a 3-cylinder diesel liquid-cooled engine, coupled to a hydrostatic transmission and four-wheel drive. The tractor's listed weight ranges from 1819 to 1863 pounds. It is designed for use in areas of approximately up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

22 hp

Max power

25.6 hp

Weight

1819 to 1863 pounds

Catalogue coverage

Variants represented

Richest spec table

114 rows

Recorded power

22 hp

Recorded weight

322 kg

Transmissions

8-speed synchro-shuttle

Production years

2014-2019

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMahindraReference

ManufacturerMitsubishiReference

Compact Utility tractorReference

Original price$15,470 (2016 shuttle )Reference

Original price$27,243 (2016 hydro cab )Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional.Reference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Fuel tank23.1 LReference

Engine19.1 kWReference

Mitsubishi S3L2Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

EmissionsTier IVReference

Power19.1 kWReference

Fuel systemindirect injectionReference

Compression22:1Reference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,600 RPMReference

Emissions complianceTier IVReference

Bore and stroke3.071x3.622 inchesReference

Compression ratio22:1Reference

Cooling systemliquid-cooledReference

Transmission

8-speed synchro-shuttleReference

hydrostaticReference

Typesynchro-shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeSync ShuttleReference

Wheel Drive4WDReference

PTO & Hydraulics

Shuttle PTO (claimed)16.0 kWReference

Hydro PTO (claimed)14.9 kWReference

Typeopen centerReference

Rear valves1Reference

Pump flow22.0 lpmReference

Steering flow10.2 lpmReference

Rear TypeIReference

Controlposition controlReference

Rear lift1000 kgReference

Rear PTOtransmissionReference

Rear PTOliveReference

Rear PTO Type540Reference

Engine RPM540@2376Reference

Mid PTO Type2000Reference

Engine RPM2000@2526Reference

Dimensions

Weight1819 to 1863 poundsReference

Front tire7x12Reference

Rear tire9.5x16Reference

Weight322 kgReference

Standard tires (ag)Front: 7x12. Rear: 9.5x16Reference

Lawn/turf front23x8.5-12Reference

Lawn/turf rear33x12.5-16.5Reference

Industrial front23x8.5-12Reference

Industrial rear12x16.5Reference

Length277 cmReference

Width137 cmReference

Height (ROPS)214 cmReference

ROPS shuttle Weight825 kgReference

ROPS hydro Weight845 kgReference

Mahindra Max 26XL attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Battery AH35Reference

Battery size35 AHReference

Attachment overview

Front-end loaderReference

BackhoeReference

Mahindra Max 26B Backhoe

Backhoe typeMahindra Max 26B BackhoeReference

Transport height180 cmReference

Digging depth203 cmReference

2-Foot flat digging depth199 cmReference

Reach from pivot259 cmReference

Loading height157 cmReference

Bucket Rotation180°Reference

Swing Arc150°Reference

Bucket force907 kgReference

Dipperstick force1029 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post folding ROPSReference

Capacities

Capacity80.4 ciReference

Power

Max Power25.6 hpReference

PTO

PTO Power21.5 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Engine Speed on Mid PTO speed2,000@2,526 RPMReference

Engine Speed on Rear PTO speed540@2,376 RPMReference

Steering & brakes

BrakesWet disc brakesReference

Steering typePower steeringReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1(opt) ValvesReference

Steering & Implements flow2.7 gpm (5.8 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity1,000.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS214.1 cmReference

Overall Length277.6 cmReference

Overall Width137.9 cmReference

Overall weight845 kgReference

Operator station

Cab AvailabilityCab optional.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
