Tractor · 2012Unverified

Mahindra Max 28 XL

Name: Mahindra Max 28 XL
Brand: Mahindra

Mahindra Max 28 XL — Max Series · 24 hp. Reference specifications; pending source verification.

The Mahindra Max 28 XL is a compact tractor with a rated output of 24 hp, produced between 2012 and 2014. It features a 3-cylinder diesel liquid-cooled engine, coupled with a hydrostatic transmission and four-wheel drive. The tractor's listed weight ranges from 1819 to 1863 pounds. It is designed for use in jobs covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

24 hp

Max power

28 hp

Weight

1819 to 1863 pounds

Catalogue coverage

Variants represented

Richest spec table

110 rows

Recorded power

24 hp

Recorded weight

825 kg

Transmissions

8-speed synchronized shuttle

Production years

2012-2014

Verified variants

No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.

Hover a source tag to verify

Overview

DistributorMahindraReference

ManufacturerMitsubishiReference

Sub-Compact Utility tractorReference

Original price$14,750 (2012 hydro )Reference

Original price$13,750 (2012 shuttle )Reference

Four-wheel driveReference

Steeringhydrostatic powerReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

Mitsubishi 1.3L 3-cyl dieselReference

Fuel tank23.1 LReference

Engine20.9 kWReference

Mitsubishi S3L2Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.3 LReference

Bore/Stroke78 x 92 mmReference

Power20.9 kWReference

Fuel systemdirect injectionReference

Compression22:1Reference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,600 RPMReference

Bore and stroke3.071x3.622 inchesReference

Compression ratio22:1Reference

Cooling systemliquid-cooledReference

Transmission

8-speed synchronized shuttleReference

hydrostaticReference

Gear Operating weight825 kgReference

Typesynchronized shuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

TypehydrostaticReference

Gearsinfinite forward and reverse (2-range)Reference

Transmission TypeSync ShuttleReference

Wheel Drive4WDReference

PTO & Hydraulics

Gear PTO (claimed)17.5 kWReference

Hydro PTO (claimed)16.4 kWReference

Typeopen centerReference

Valves1 (optional)Reference

Pump flow17.4 lpmReference

Steering flow10.2 lpmReference

Rear Type1Reference

Controlposition controlReference

Rear lift1000 kgReference

Rear PTOtransmissionReference

Rear PTO Type540Reference

Engine RPM540@2376Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Engine RPM2000@2556Reference

Dimensions

Weight1819 to 1863 poundsReference

Front tire7x12Reference

Rear tire9.5x16Reference

Standard tires (ag)Front: 7x12. Rear: 9.5x16Reference

Lawn/turf front23x8.5-12Reference

Lawn/turf rear33x12.5-16.5Reference

Industrial front23x8.5-12Reference

Industrial rear12x16.5Reference

Length277 cmReference

Width137 cmReference

Hydro Operating weight845 kgReference

Mahindra Max 28 XL attachments

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps50Reference

Battery volts12Reference

Battery AH35Reference

Battery size35 AHReference

Attachment overview

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

Mahindra MB63A Backhoe

Backhoe typeMahindra MB63A BackhoeReference

Digging depth193 cmReference

2-Foot flat digging depth190 cmReference

Reach from pivot259 cmReference

Loading height157 cmReference

Bucket Rotation180°Reference

Swing Arc150°Reference

Bucket force972 kgReference

Dipperstick force409 kgReference

General

Make & ModelMahindraReference

Rollover protective structureTwo-post foldable ROPS.Reference

Capacities

Capacity80.4 ciReference

Power

Max Power28 hpReference

PTO

PTO Power23.5 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTO RPM2,000 RPMReference

Engine Speed on Rear PTO speed540@2,376 RPMReference

Engine Speed on Mid PTO speed2,000@2,556 RPMReference

Steering & brakes

Brakeswet discReference

Steering typehydrostatic powerReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves1 (optional) ValvesReference

Steering & Implements flow2.7 gpm (4.6 gpm)Reference

Rear Hitch category (SAE designation)Category 1Reference

Rear Hitch maximum lift capacity1,000.2 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Overall Length277.6 cmReference

Overall Width137.9 cmReference

Overall weight845 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
