Tractor · 1992Unverified
Marshall 264
Marshall 264 — Compact Utility tractor · 26 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
26 hp
Weight
700 kg
Hover a source tag to verify
Overview
DistributorMarshallReference
ManufacturerFerrariReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Manual steeringReference
Mechanical drum brakesReference
Two-post fixed ROPS.Reference
Engine
Lombardini 1.1L 2-cyl dieselReference
Fuel tank9.8 LReference
Engine19.2 kWReference
Lombardini 9LD561-2Reference
dieselReference
2-cylinderReference
air-cooledReference
Displacement1.1 LReference
Bore/Stroke90 x 88 mmReference
Power19.2 kWReference
Air cleaneroil bathReference
Compression17.5:1Reference
Rated RPM3000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity3.5 LReference
Transmission
6-speed gearReference
12-speed gearReference
TypegearReference
Gears6 forward and 3 reverseReference
Clutchmechanical dry discReference
Oil capacity17.6 LReference
Gears12 forward and 6 reverseReference
PTO & Hydraulics
Typeopen centerReference
Pressure165.5 barReference
Valves2Reference
Pump flow12.1 lpmReference
Rear TypeIReference
Rear lift (at ends)548 kgReference
Rear PTO Type540/1000 (1.375)Reference
Engine RPM540@2700Reference
Engine RPM1000@2700Reference
Dimensions
Wheelbase137 cmReference
Weight700 kgReference
Front tire6.00-12Reference
Rear tire8.25-16Reference
Ag front6.00-12Reference
Ag rear8.25-16Reference
Length218 cmReference
Width100 cmReference
Height118 cmReference
Front tread81 to 88 cmReference
Rear tread78 to 96 cmReference
Electrical
GroundnegativeReference
Charging systemgeneratorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
