The Marshall 754 is a tractor with a rated output of 61 hp — making it one of the more compact options in its class. Power comes from a 4-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a hydrostatic transmission. It is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
61 hp
Catalogue coverage
Variants represented
2
Richest spec table
39 rows
Recorded power
61 hp
Transmissions
9-speed
Verified variants
0
No linked source document is currently displayed; verify critical figures with the manufacturer or dealer.
Hover a source tag to verify
Overview
ManufacturerMarshallReference
Drive4x4 4WDReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Explorer cab with heaterReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank135.9 LReference
Engine55.2 kWReference
Perkins 4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power55.2 kWReference
Compression16:1Reference
Rated RPM2200Reference
Oil capacity8.0 LReference
Coolant capacity14.5 LReference
Transmission
9-speedReference
15-speedReference
Gears9 forward and 3 reverseReference
Gears15 forward and 5 reverseReference
PTO & Hydraulics
PTO (claimed)45.5 kWReference
Pressure179.3 barReference
Total flow59.0 lpmReference
Rear TypeIIReference
Dimensions
Wheelbase233 cmReference
Front tire12.4/11-28Reference
Rear tire13.6/12-38Reference
Ag front12.4/11-28Reference
Ag rear13.6/12-38Reference
Length394 cmReference
Width195 cmReference
Height264 cmReference
Ground clearance43 cmReference
Electrical
Charging amps36Reference
Battery CCA510Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
