Marshall 852
Marshall 852 · 73 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
73 hp
Hover a source tag to verify
Overview
ManufacturerMarshallReference
Two-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Explorer cab with heaterReference
Engine
Perkins 3.9L 4-cyl dieselReference
Fuel tank135.9 LReference
Engine63.4 kWReference
Perkins T4.236Reference
turbocharged dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Power63.4 kWReference
Compression16:1Reference
Rated RPM2200Reference
Oil capacity8.0 LReference
Coolant capacity14.5 LReference
Transmission
9-speedReference
15-speedReference
Gears9 forward and 3 reverseReference
Gears15 forward and 5 reverseReference
PTO & Hydraulics
PTO (claimed)54.4 kWReference
Pressure179.3 barReference
Total flow59.0 lpmReference
Rear TypeIIReference
Dimensions
Wheelbase224 cmReference
Length389 cmReference
Width195 cmReference
Height264 cmReference
Ground clearance45 cmReference
Electrical
Charging amps36Reference
Battery CCA510Reference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
