Lawn Tractor · 1966Unverified
Massey Ferguson 10
Massey Ferguson 10 — Garden tractor · 10 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
10 hp
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerAMFReference
Garden tractorReference
FactoriesAlgoma, Wisconsin, USAReference
FactoriesDes Moines, Iowa, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
10HP Tecumseh 388cc 1-cyl gasolineReference
Fuel tank6.6 LReference
Tecumseh HH100Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement23.7 ciReference
Bore/Stroke84 x 70 mmReference
Power7.5 kWReference
Starter volts12Reference
Oil capacity1.2 LReference
Transmission
4-speed gear with variable-speed pulleyReference
Typebelt-driven gear with variable-speed pulleyReference
Gears4 forward and 1 reverseReference
Oil capacity1.9 LReference
Right-hand variable speed control offers five shift-on-the-go speed ratios for each gear in in the transmission.Reference
PTO & Hydraulics
Typesleeve hitch (optional)Reference
Dimensions
Wheelbase111 cmReference
Front tire4.80x8.00Reference
Rear tire6.00x12.00Reference
Ag front4.80x8.00Reference
Ag rear6.00x12.00Reference
Lawn/turf front4.80x8.00Reference
Lawn/turf rear6.00x12.00Reference
Lawn/turf front6.50x8.00Reference
Lawn/turf rear8.50x12.00Reference
Length170 cmReference
Width90 cmReference
Height (steering wheel)106 cmReference
Ground clearance17 cmReference
Massey Ferguson 10 attachments
42" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
10 Serial Number Location
Serial number plate on the left side of the MF10, below the instrument panel.Reference
10 Serial Numbers
196600001Reference
196706016Reference
196814045Reference
196916182Reference
197019156Reference
197123899Reference
1972-----Reference
1973-----Reference
1974-----Reference
197526127Reference
197628227Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
42" Mower deck
Typemid-mount Massey FergusonReference
Type3-bladeReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
