The Massey Ferguson 1024 is a tractor with a rated power of 127 hp, positioning it at the higher power end of its class. The model was manufactured from 1978 to 1990. It features a 6-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a hydrostatic transmission. The tractor has a listed operating weight of 5000 kg and is suitable for operations of 200–800 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
127 hp
Weight
5000 kg
Catalogue coverage
Variants represented
2
Richest spec table
33 rows
Recorded power
127 hp
Recorded weight
5000 kg
Transmissions
12-speed
Production years
1978-1990
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerLandiniReference
Row-Crop tractorReference
Four-wheel driveReference
Steeringhydrostatic powerReference
Wet disc brakesReference
Cab standardReference
Engine
Perkins 5.8L 6-cyl dieselReference
Fuel tank169.9 LReference
Engine94.7 kWReference
Perkins A6.354.4Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke98 x 127 mmReference
Power94.7 kWReference
Rated RPM2400Reference
Torque400.0 NmReference
Torque RPM1400Reference
Transmission
12-speedReference
Gears12 forward and 4 reverseReference
PTO & Hydraulics
Total flow53.0 lpmReference
Rear lift4701 kgReference
Rear PTO Type540/1000Reference
Dimensions
Wheelbase261 cmReference
Weight5000 kgReference
Front tire13.6-28Reference
Rear tire18.4-38Reference
Ag front13.6-28Reference
Ag rear18.4-38Reference
Length440 cmReference
Height281 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
