Tractor · 1984Unverified

Massey Ferguson 1040

Name: Massey Ferguson 1040
Brand: Massey Ferguson

Massey Ferguson 1040 — Compact Utility tractor · 27 hp. Reference specifications; pending source verification.

The Massey Ferguson 1040 is a tractor model rated at 27 hp — making it one of the more compact options in its class. It was manufactured from 1984 to 1986. Under the hood is a 3-cylinder diesel liquid-cooled engine, driving through four-wheel drive with a 12-speed gearbox. Listed weight is 3350 to 3675 pounds, and it is aimed at jobs of around up to 200 ac. The available specification table below shows both UK and US units.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

27 hp

Weight

3350 to 3675 pounds

Catalogue coverage

Variants represented

Richest spec table

75 rows

Recorded power

27 hp

Recorded weight

1519 kg

Transmissions

12-speed gear

Production years

1984-1986

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerToyoshaReference

Compact Utility tractorReference

Original price was $10,800 in 1986Reference

Two- or four-wheel driveReference

SteeringpowerReference

Mechanical disc brakesReference

Two-post ROPS.Reference

Engine

Toyosha 2.0L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine23.9 kWReference

Toyosha 3D200Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.0 LReference

Bore/Stroke92 x 100 mmReference

Power23.9 kWReference

Fuel systemdirect injectionReference

Rated RPM2500Reference

Firing order1-3-2Reference

Starter volts12Reference

Oil capacity5.5 LReference

Coolant capacity8.0 LReference

Transmission

12-speed gearReference

TypegearReference

Gears12 forward and 3 reverseReference

Clutch240mm dry discReference

Oil capacity44.0 LReference

PTO & Hydraulics

PTO (claimed)20.1 kWReference

Typeopen centerReference

Pump flow24.6 lpmReference

Rear TypeIReference

Rear lift (at ends)784 kgReference

Rear PTOliveReference

Rear PTO Type540Reference

Front PTOindependent (optional)Reference

ClutchelectricReference

Dimensions

Wheelbase177 cmReference

Weight3350 to 3675 poundsReference

Front tire5.50-16Reference

Rear tire13.6x24 (2WD)Reference

Standard tires (ag)Front: 5.50-16. Rear: 13.6x24 (2WD)Reference

Standard tires (ag)Front: 8.00x16. Rear: 13.6x24 (4WD)Reference

Ag rear13.6-24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear18.4x16.1Reference

Length292 cmReference

Width148 cmReference

Height (steering wheel)153 cmReference

Shipping weight1519 kgReference

Shipping weight1666 kgReference

Massey Ferguson 1040 attachments

72" mid-mount mower deckReference

bladeReference

front-end loaderReference

backhoeReference

1040 Serial Number Location

Serial number plate on the right side of the transmission housing.Reference

1040 Serial Numbers

198400101 (2WD)Reference

198500155 (2WD)Reference

198600552 (2WD)Reference

198440101 (4WD)Reference

198540351 (4WD)Reference

198640562 (4WD)Reference

198740773 (4WD)Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

72" mid-mount mower deckReference

BladeReference

Massey Ferguson 1016 loaderReference

Massey Ferguson 232 loaderReference

BackhoeReference

72" Mower deck

Typemid-mount Massey Ferguson 1019Reference

Cutting width182 cmReference

Massey Ferguson 1017 Backhoe

Backhoe typeMassey Ferguson 1017 BackhoeReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
