Tractor · 1971Unverified
Massey Ferguson 1078
Massey Ferguson 1078 — Row-Crop tractor · 75 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
75 hp
Weight
4556 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Built in Granadero Baigorria, Santa Fe, ArgentinaReference
Two-wheel driveReference
Power steeringReference
Disc brakesReference
Open operator station.Reference
Engine
Perkins 5.0L 6-cyl dieselReference
Engine55.9 kWReference
Perkins A.6-305Reference
dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.0 LReference
Bore/Stroke91 x 127 mmReference
Power55.9 kWReference
Rated RPM2000Reference
StarterelectricReference
Starter volts12Reference
Oil capacity13.7 LReference
Coolant capacity15.0 LReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Clutch304.8mm dry discReference
Oil capacity34.1 LReference
Capacities
Fuel85.2 LReference
PTO & Hydraulics
Hydraulic system34.1 LReference
Capacity34.1 LReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1680Reference
Dimensions
Wheelbase234 cmReference
Weight4556 kgReference
Front tire7.50x18Reference
Rear tire18.4x34Reference
Ag front7.50x18Reference
Ag rear18.4x34Reference
Ag front6.50x15Reference
Ag rear15.5x38Reference
Length368 cmReference
Width219 cmReference
Height (steering wheel)180 cmReference
Ground clearance55 cmReference
Electrical
GroundnegativeReference
Batteries2Reference
Battery volts12Reference
Battery AH86Reference
Speeds
Speeds with 18.4x34 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
