Tractor · 1973Unverified

Massey Ferguson 1105

Massey Ferguson 1105 — Row-Crop tractor · 111 hp. Reference specifications; pending source verification.

The Massey Ferguson 1105 tractor has a rating of approximately 111 horsepower, a mid-range figure for its class. It was produced from 1973 to 1978 and features a 6-cylinder turbocharged diesel liquid-cooled engine, paired with two-wheel drive and a powershift transmission. The tractor's operating weight is listed as 10750 to 12320 pounds, and it is suitable for operations on areas of 200–800 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
111 hp
Max power
62.3 kW
Weight
10750 to 12320 pounds

Catalogue coverage

Variants represented
2
Richest spec table
118 rows
Recorded power
111 hp
Transmissions
12-speed two-speed power shift
Production years
1973-1978
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference
Row-Crop tractorReference
Original price was $20,000 in 1978Reference
Two-wheel driveReference
Power steeringReference
Hydraulic disc brakesReference
Cab optional.Reference

Engine

Perkins 5.8L 6-cyl dieselReference
Drawbar (claimed)61.9 kWReference
Drawbar (tested)62.3 kWReference
Perkins ATC6.3541Reference
turbocharged dieselReference
6-cylinderReference
liquid-cooledReference
Displacement5.8 LReference
Bore/Stroke98 x 127 mmReference
Fuel systemdirect injectionReference
Air cleanerdryReference
Compression16:1Reference
Rated RPM2200Reference
Starter volts12Reference
Oil capacity15.1 LReference
Coolant capacity20.8 LReference
Power at rated engine speed82.6 kWReference
Max power62.3 kWReference
Fuel TypeDieselReference
No of Cylinders6-cylinderReference
Rated engine speed2,200Reference
Bore and stroke3.875x5.00 inchesReference
Compression ratio16:1Reference
Cooling systemliquid-cooledReference

Transmission

12-speed two-speed power shiftReference
8-speed gearReference
TransmissionMulti-PowerReference
Typetwo-speed power shiftReference
Gears12 forward and 4 reverseReference
Clutch356mm dry discReference
Three gears (1-3), plus reverse (R) in two ranges (low-high), with additional two-speed Multi-Power power shift.Reference
TypegearReference
Gears8 forward and 2 reverseReference
Transmission TypePowershiftReference

PTO & Hydraulics

PTO (claimed)82.8 kWReference
PTO (tested)82.6 kWReference
Hydraulic system83.3 LReference
Typeclosed centerReference
Capacity83.3 LReference
Pressure144.8 barReference
Pump flow75.7 lpmReference
Rear TypeII/IIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Rear PTO Type540/1000Reference
Engine RPM540@2000Reference
Engine RPM1000@2000Reference
Power at rated PTO speed71.9 kWReference

Capacities

Fuel208.2 LReference

Dimensions

Wheelbase276 cmReference
Weight10750 to 12320 poundsReference
Front tire11.00-16Reference
Rear tire18.4-38Reference
Ag front11.00-16Reference
Ag rear18.4-38Reference
Length457 cmReference
Clearance (front axle)63 cmReference
Clearance (drawbar)40 cmReference
Rear axle82 by 2387 mmReference
Rear axle82 by 2895 mmReference
Front tread155 to 219 cmReference
Front tread156 cmReference
Rear tread177 to 238 cmReference
Rear tread152 to 254 cmReference
Rear tread177 to 289 cmReference
Rear tread152 to 304 cmReference
Shipping4876 kgReference
Shipping5443 kgReference
Operating5588 kgReference
Ballasted7586 kgReference
Steering wheel200 cmReference

Massey Ferguson 1105 attachments

front-end loaderReference

1105 Serial Numbers

Location:In front of instrument panel on left sideReference
19729B36563Reference
19739B36851Reference
19749B42685Reference
19759B50494Reference
19769B58735Reference
19779B66276Reference
19789B74241Reference
19799B76058Reference
FAQ: How to read a serial number table.Reference

Electrical

Charging systemalternatorReference
Battery volts12Reference

Attachment overview

Massey Ferguson 245 loaderReference
Massey Ferguson 245 High Lift loaderReference

Massey Ferguson 1105 Height

Hood193 cmReference
Cab288 cmReference

Test results

Diesel MultiPower 2WDMay 29 - June 8, 1973Link: Nebraska Tractor Test 1132 fileReference
PTO performanceReference
Fuel use28.4 l/hourReference
Fuel use23.5 l/hourReference
Drawbar performanceReference
Fuel use25.7 l/hourReference
Gear 3LL-MP used for power test.Reference
Max pull5155 kgReference
Gear 1HL-MP used for pull test.Reference

Speeds

With 18.4x38 rear tires.Reference
With 18.4-38 rear tires.Reference

General

Make & ModelMassey FergusonReference
Rear Axle Type238.8 cmReference

PTO

Rear PTO PowerAvailableReference

Hydraulics

Hydraulics Typeclosed centerReference
Maximum operating pressure2,100 psiReference
Rear Hitch category (SAE designation)Category II/IIIReference
Rear Hitch Sensing Typeposition and draft controlReference

Dimensions & weight

Overall Length457.2 cmReference
Drawbar clearance40.9 cmReference
Front axle clearance63.5 cmReference

Wheels & tyres

Rear wheel tread range18.4-38 inchReference
Front Wheel tread rangeOption 1: 11.00-16\\nOption 2: 61.4 to 86.4 inches, 61.6 inchesReference
