Tractor · 1991Unverified
Massey Ferguson 1145
Massey Ferguson 1145 — Compact Utility tractor · 31 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
31 hp
Weight
1275 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Original price was $16,000 in 1992Reference
Four-wheel driveReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post fixed ROPS.Reference
Engine
Isuzu 1.5L 3-cyl dieselReference
Engine26.1 kWReference
Isuzu E3AD1-HTO1Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power26.1 kWReference
Fuel systemindirect injectionReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2600Reference
Torque113.2 NmReference
Torque RPM1800Reference
Firing order1-3-2Reference
Starter volts12Reference
Oil capacity4.8 LReference
Coolant capacity6.8 LReference
Transmission
16-speed partially synchronizedReference
Typepartially synchronizedReference
Gears16 forward and reverseReference
Clutch225mm dry discReference
Four gears (1-4) in four ranges (1-4) with synchronized shuttle shifting. Gears three and four are synchronized.Reference
PTO & Hydraulics
PTO (claimed)23.1 kWReference
Hydraulic system25.0 LReference
Typeopen centerReference
Capacity25.0 LReference
Pressure147.1 barReference
Pump flow26.1 lpmReference
Steering cap.2.6 LReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1300 kgReference
Rear lift (at 24"/610mm)809 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type1950 (1.00 15-spline)Reference
Engine RPM1960@2600Reference
Capacities
Fuel30.3 LReference
Steering2.6 LReference
Dimensions
Wheelbase170 cmReference
Weight1275 kgReference
Front tire8-16Reference
Rear tire13.6-24Reference
Ag front8-16Reference
Ag rear13.6-24Reference
Length307 cmReference
Width142 cmReference
Height (ROPS)211 cmReference
Operating weight1275 kgReference
Ground clearance32 cmReference
Massey Ferguson 1145 attachments
front-end loaderReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
