Tractor · 1970Unverified
Massey Ferguson 1150
Massey Ferguson 1150 — Row-Crop tractor · 136 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
136 hp
Max power
89.5 kW
Weight
13370 to 13590 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Original price was $14,000 in 1972Reference
Two-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Differential hydraulic disc brakesReference
Open operator station. Cab optional with available air-conditioning.Reference
Engine
Perkins 8.3L 8-cyl dieselReference
Engine108.9 kWReference
Drawbar (claimed)89.5 kWReference
Drawbar (tested)89.5 kWReference
Perkins AV8.510Reference
dieselReference
8-cylinder 16-valveReference
liquid-cooled V-8Reference
Displacement8.3 LReference
Bore/Stroke108 x 114 mmReference
Power108.9 kWReference
Air cleanerdual dry elementReference
Compression17.5:1Reference
Rated RPM2200Reference
Torque730.9 NmReference
Torque RPM1450Reference
Starter volts12Reference
Oil capacity18.9 LReference
Coolant capacity45.4 LReference
Power at rated engine speed101.1 kWReference
Max power89.5 kWReference
Transmission
12-speed two-speed power shiftReference
TransmissionMulti-PowerReference
Typetwo-speed power shiftReference
Gears12 forward and 4 reverseReference
Clutch279.4mm cerametallic discReference
Oil capacity60.6 LReference
Three gears in two ranges with the two-speed Multi-Power power shift.Reference
PTO & Hydraulics
PTO (claimed)100.7 kWReference
PTO (tested)101.1 kWReference
Hydraulic system64.3 LReference
Typeclosed centerReference
Capacity64.3 LReference
Valves2Reference
Pump flow75.7 lpmReference
Rear TypeIIReference
Controlposition and draft controlReference
Rear PTOindependentReference
Clutchwet discReference
Rear PTO Type540/1000 (1.375)Reference
Power at rated PTO speed96.0 kWReference
Capacities
Fuel189.2 LReference
Dimensions
Wheelbase274 cmReference
Weight13370 to 13590 poundsReference
Front tire11.00-16Reference
Rear tire18.4-34Reference
Ag front11.00-16Reference
Ag rear18.4-34 (row-crop)Reference
Ag rear18.4-38 (Western)Reference
Ag rear23.1x34Reference
Ag rear24.5x32Reference
Ag rear30.5x32 (Western)Reference
Length434 cmReference
Width238 cmReference
Height (steering wheel)189 cmReference
Height (cab)288 cmReference
Clearance (front axle)80 cmReference
Clearance (drawbar)40 cmReference
Rear axle82 mmReference
Front tread142 to 20 cmReference
Rear tread152 to 243 cmReference
Rear tread152 to 304 cmReference
Shipping6064 kgReference
Operating6164 kgReference
Ballasted10262 kgReference
1150 Serial Numbers
Location:Ahead of instrument panel on right side.Reference
19709B23486Reference
19719B28238Reference
19729B31959Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Batteries2Reference
Battery volts12Reference
Test results
Diesel 12-speed 2WDSeptember 11 - 19, 1970Link: Nebraska Tractor Test 1049 fileReference
PTO performanceReference
Fuel use34.1 l/hourReference
Fuel use32.2 l/hourReference
Drawbar performanceReference
Fuel use33.7 l/hourReference
Gear 3L-L used for power test.Reference
Max pull7829 kgReference
Gear 1L-H used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
