Tractor · 1992Unverified

Massey Ferguson 1160

Name: Massey Ferguson 1160
Brand: Massey Ferguson

Massey Ferguson 1160 — Compact Utility tractor · 37 hp. Reference specifications; pending source verification.

The Massey Ferguson 1160 is a tractor with an output of approximately 37 hp, categorising it as a relatively lightweight model within its class. It was produced from 1992 to 1999. The tractor features a 4-cylinder diesel liquid-cooled engine and a 16-speed gearbox with four-wheel drive. Its operating weight is listed at 1745 kg, with a maximum operating capacity of 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

37 hp

Weight

1745 kg

Catalogue coverage

Variants represented

Richest spec table

76 rows

Recorded power

37 hp

Recorded weight

1745 kg

Transmissions

16-speed synchronized shuttle

Production years

1992-1999

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Compact Utility tractorReference

Original price was $24,700 in 1999Reference

Four-wheel driveReference

SteeringpowerReference

Mechanical wet disc brakesReference

Two-post fixed ROPS.Reference

Variants

TA417similar Iseki modelReference

Engine

Isuzu 2.2L 4-cyl dieselReference

Engine30.6 kWReference

Isuzu 4JC1Reference

dieselReference

4-cylinderReference

liquid-cooledReference

Displacement2.2 LReference

Bore/Stroke88 x 92 mmReference

Power30.6 kWReference

Fuel systemdirect injectionReference

Air cleanerdual dry elementReference

Pre-heatingglow plugsReference

Rated RPM2500Reference

Torque248.1 NmReference

Torque RPM1600Reference

Starter volts12Reference

Coolant capacity9.1 LReference

Transmission

16-speed synchronized shuttleReference

Typesynchronized shuttleReference

Gears16 forward and reverseReference

Clutch260mm discReference

Four gears (1-4) in four ranges (LL, L, M, and H) with shuttle. Gears 3 and 4 are synchronized.Reference

PTO & Hydraulics

PTO (claimed)27.6 kWReference

Hydraulic system29.1 LReference

Typeopen centerReference

Capacity29.1 LReference

Pressure156.9 barReference

Valves0 to 2Reference

Pump flow31.0 lpmReference

Rear TypeIReference

Controldraft, position, and response controlReference

Rear lift (at ends)1399 kgReference

Rear lift (at 24"/610mm)1179 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Capacities

Fuel48.1 LReference

Dimensions

Wheelbase189 cmReference

Weight1745 kgReference

Front tire9.5x16Reference

Rear tire13.6x28Reference

Ag front9.5x16Reference

Ag rear13.6x28Reference

Lawn/turf front212/80D-15Reference

Lawn/turf rear475/65D-20Reference

Length330 cmReference

Width149 cmReference

Height (ROPS)226 cmReference

Shipping weight1745 kgReference

Ground clearance30 cmReference

Front tread127 cmReference

Rear tread115 to 147 cmReference

Massey Ferguson 1160 attachments

front-end loaderReference

1160 Serial Numbers

1992A70101Reference

1993B70101Reference

1994C00101Reference

1995D00101Reference

1996E00101Reference

1997F01001Reference

1998G01001Reference

1999H01001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps45Reference

Battery CCA662Reference

Battery volts12Reference

Speeds

With 13.6x28 rear tires. Reverse speeds are 9% slower than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
