Tractor · 1992Unverified

Massey Ferguson 1180

Massey Ferguson 1180 — Compact Utility tractor · 46 hp. Reference specifications; pending source verification.

The Massey Ferguson 1180 is a tractor model with a rated power of 46 hp, positioning it at the lighter end of its class. Manufactured from 1992 to 1999, this model features a 4-cylinder diesel liquid-cooled engine, paired with four-wheel drive and a 16-speed gearbox. It has an operating weight of 1974 kg, making it suitable for operations of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
46 hp
Weight
1974 kg

Catalogue coverage

Variants represented
2
Richest spec table
76 rows
Recorded power
46 hp
Recorded weight
1974 kg
Transmissions
16-speed synchronized shuttle
Production years
1992-1999
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference
Compact Utility tractorReference
Original price was $26,800 in 1999Reference
Four-wheel driveReference
SteeringpowerReference
Mechanical wet disc brakesReference
Two-post fixed ROPS.Reference

Variants

TA527similar Iseki modelReference

Engine

Isuzu 2.8L 4-cyl dieselReference
Engine38.8 kWReference
Isuzu 4JB1Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
Bore/Stroke93 x 102 mmReference
Power38.8 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementReference
Pre-heatingglow plugsReference
Rated RPM2500Reference
Torque176.3 NmReference
Torque RPM1600Reference
Starter volts12Reference
Oil capacity7.0 LReference
Coolant capacity9.0 LReference

Transmission

16-speed synchronized shuttleReference
Typesynchronized shuttleReference
Gears16 forward and reverseReference
Clutch275mm discReference
Four gears (1-4) in four ranges (LL, L, M, and H) with shuttle. Gears 3 and 4 are synchronized.Reference

PTO & Hydraulics

PTO (claimed)34.3 kWReference
Hydraulic system32.2 LReference
Typeopen centerReference
Capacity32.2 LReference
Pressure166.7 barReference
Valves0 to 2Reference
Pump flow31.0 lpmReference
Rear TypeIReference
Controlposition, draft, and response controlReference
Rear lift (at ends)2199 kgReference
Rear lift (at 24"/610mm)1834 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference

Capacities

Fuel51.1 LReference

Dimensions

Wheelbase202 cmReference
Weight1974 kgReference
Front tire9.5-18Reference
Rear tire14.9-28Reference
Ag front9.5-18Reference
Ag rear14.9-28Reference
Lawn/turf front29x12.00-15Reference
Lawn/turf rear475/65D-20Reference
Length346 cmReference
Width154 cmReference
Height (ROPS)230 cmReference
Ground clearance33 cmReference
Front tread128 cmReference
Rear tread123 to 164 cmReference

Massey Ferguson 1180 attachments

front-end loaderReference

1180 Serial Numbers

1992A80101Reference
1993B80101Reference
1994C00101Reference
1995D00101Reference
1996E00101Reference
1997F01001Reference
1998G01001Reference
1999H01001Reference
FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery CCA799Reference
Battery volts12Reference

Speeds

With 14.9x28 rear tires. Reverse speeds are 5% slower than forward.Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
