Lawn Tractor · 1967Unverified
Massey Ferguson 12
Massey Ferguson 12 — Garden tractor · 12 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerAMFReference
Garden tractorReference
FactoriesAlgoma, Wisconsin, USAReference
FactoriesDes Moines, Iowa, USAReference
Two-wheel driveReference
Manual steeringReference
Mechanical band brakesReference
Open operator station.Reference
Engine
12HP Tecumseh 454cc 1-cyl gasolineReference
Fuel tank9.5 LReference
Tecumseh HH120Reference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement27.7 ciReference
Bore/Stroke89 x 73 mmReference
Power8.9 kWReference
Rated RPM3600Reference
Starter volts12Reference
Transmission
hydrostaticReference
4-speed gear with variable-speed pulleyReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
Oil capacity1.9 LReference
Typebelt-driven gear with variable-speed pulleyReference
Gears4 forward and 1 reverseReference
Right-hand variable speed control offers five shift-on-the-go speed ratios for each gear in in the transmission.Reference
PTO & Hydraulics
Typesleeve hitchReference
Dimensions
Wheelbase111 cmReference
Front tire4.80x8.00Reference
Rear tire6.00x12.00Reference
Ag front4.80x8.00Reference
Ag rear6.00x12.00Reference
Lawn/turf front4.80x8.00Reference
Lawn/turf rear6.00x12.00Reference
Lawn/turf front6.50x8.00Reference
Lawn/turf rear8.50x12.00Reference
Length170 cmReference
Width90 cmReference
Height (steering wheel)106 cmReference
Ground clearance17 cmReference
Massey Ferguson 12 attachments
42" mid-mount mower deckReference
snowblowerReference
front-end loaderReference
12 Serial Number Location
Serial number plate on the left side of the MF12, below the dash.Reference
12 Serial Numbers
1967500001 (Hydrostatic)Reference
1968502904 (Hydrostatic)Reference
1969506952 (Hydrostatic)Reference
1970510578 (Hydrostatic)Reference
1971515384 (Hydrostatic)Reference
1972517709 (Hydrostatic)Reference
1972800001 (Gear)Reference
1973803352 (Gear)Reference
1974806983 (Gear)Reference
1975810481 (Gear)Reference
1976812843 (Gear)Reference
FAQ: How to read a serial number table.Reference
Attachment overview
42" mid-mount mower deckReference
SnowblowerReference
Front-end loaderReference
42" Mower deck
Typemid-mount Massey FergusonReference
Type3-bladeReference
Cutting width106 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
