Tractor · 1992Unverified
Massey Ferguson 1250
Massey Ferguson 1250 — Compact Utility tractor · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
2690 to 2746 pounds
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Original price was $16,000 in 1999Reference
Two- or four-wheel driveReference
Steeringpower assistReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)24.6 kWReference
Engine (net)23.6 kWReference
Iseki E3CDReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (net)23.6 kWReference
Power (gross)24.6 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Compression21.8:1Reference
Rated RPM2600Reference
Torque100.3 NmReference
Torque RPM1600Reference
Starter volts12Reference
Coolant capacity6.5 LReference
Transmission
16-speed synchro shuttleReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
Clutch225mm dry discReference
Four gears in four ranges with shuttle. Synchronized shifts between gears 3 and 4.Reference
PTO & Hydraulics
PTO (claimed)20.4 kWReference
Hydraulic system25.0 LReference
Typeopen centerReference
Capacity25.0 LReference
Pressure147.1 barReference
Pump flow23.8 lpmReference
Total flow36.3 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1300 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2389Reference
Mid PTOindependentReference
Mid PTO Type1960Reference
Engine RPM1960@2600Reference
Capacities
Fuel29.9 LReference
Dimensions
Wheelbase172 cmReference
Weight2690 to 2746 poundsReference
Front tire5.50-16Reference
2WD Rear tire12.4-24Reference
2WD Standard tires (ag)Front: 5.50-16. Rear: 12.4-24Reference
4WD Standard tires (ag)Front: 7-16. Rear: 12.4-24Reference
2WD Lawn/turf front24x8.50-12Reference
4WD Lawn/turf front212/80D-15Reference
Lawn/turf rear355/80D-20Reference
Length309 cmReference
Width140 cmReference
Height (ROPS)216 cmReference
Height (Folded ROPS)175 cmReference
2WD Weight1220 kgReference
4WD Weight1245 kgReference
Ground clearance30 cmReference
2WD Front tread99 to 129 cmReference
4WD Front tread107 cmReference
Rear tread109 to 141 cmReference
Massey Ferguson 1250 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
1250 Serial Numbers
1992A00001Reference
1993B00001Reference
1994C00001Reference
1995D00001Reference
1996E00001Reference
1997FF00001Reference
1998GF00001Reference
1999HF00001Reference
2000JF00001Reference
2001KF00001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA622Reference
Battery volts12Reference
Battery Group31Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount Massey Ferguson 1231Reference
Cutting width182 cmReference
Massey Ferguson 1217 Backhoe
Backhoe typeMassey Ferguson 1217 BackhoeReference
Speeds
With 12.4-24 rear tires. Reverse speeds are 5% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
