Tractor · 1992Unverified
Massey Ferguson 1260
Massey Ferguson 1260 — Compact Utility tractor · 40 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
40 hp
Weight
1451 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Original price was $20,600 in 1999Reference
The Massey Ferguson 1260 is similar to the Iseki model TK538.Reference
Four-wheel driveReference
Steeringpower assistReference
Wet disc brakesReference
Two-post foldable ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)29.8 kWReference
Engine (net)28.3 kWReference
Iseki E3AD1Reference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke86 x 86 mmReference
Power (net)28.3 kWReference
Power (gross)29.8 kWReference
Fuel systemindirect injectionReference
Air cleanerdryReference
Pre-heatingglow plugsReference
Compression21.8:1Reference
Rated RPM2600Reference
Torque118.0 NmReference
Torque RPM1600Reference
Starter volts12Reference
Coolant capacity6.5 LReference
Transmission
16-speed synchro shuttleReference
Typesynchro shuttleReference
Gears16 forward and reverseReference
Clutch240mm dry discReference
Four gears in four ranges with shuttle. Synchronized shifts between gears 3 and 4.Reference
PTO & Hydraulics
PTO (claimed)23.6 kWReference
Hydraulic system25.0 LReference
Typeopen centerReference
Capacity25.0 LReference
Pump flow23.8 lpmReference
Total flow36.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1300 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@2430Reference
Mid PTOindependentReference
Mid PTO Type1925Reference
Engine RPM1925@2600Reference
Capacities
Fuel29.9 LReference
Dimensions
Wheelbase172 cmReference
Weight1451 kgReference
Front tire8.00-16Reference
Rear tire13.6-24Reference
Ag front8.00-16Reference
Ag rear13.6-24Reference
Length309 cmReference
Width142 cmReference
Height219 cmReference
Height (Folded ROPS)177 cmReference
Ground clearance33 cmReference
Front tread112 cmReference
Rear tread109 to 141 cmReference
Massey Ferguson 1260 attachments
72" mid-mount mower deckReference
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery CCA622Reference
Battery volts12Reference
Attachment overview
72" mid-mount mower deckReference
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
72" Mower deck
Typemid-mount Massey Ferguson 1231Reference
Cutting width182 cmReference
Massey Ferguson 1217 Backhoe
Backhoe typeMassey Ferguson 1217 BackhoeReference
Speeds
With 13.6-24 rear tires. Reverse speeds are 5% slower than forward.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
