Tractor · 1966Unverified
Massey Ferguson 130
Massey Ferguson 130 — Utility tractor · 27 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
27 hp
Max power
17.0 kW
Weight
1456 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Original price was $3,564 in 1972Reference
Two-wheel driveReference
Manual steeringReference
Differential mechanical disc brakesReference
Open operator station.Reference
Variants
Economyno headlightsReference
DeluxeheadlightsReference
High Clearancehigh cropReference
Narrownarrow widthReference
Vineyardlow-profileReference
Engine
Perkins 1.8L 4-cyl dieselReference
Engine22.4 kWReference
Drawbar (claimed)17.2 kWReference
Drawbar (tested)17.0 kWReference
Perkins A4-107Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke79 x 89 mmReference
Power22.4 kWReference
Fuel use7.3 l/hourReference
Air cleaneroil bathReference
Compression22:1Reference
Rated RPM2250Reference
Torque103.1 NmReference
Torque RPM1250Reference
Starter volts12Reference
Oil capacity5.4 LReference
Coolant capacity6.7 LReference
Power at rated engine speed20.1 kWReference
Max power17.0 kWReference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
Oil capacity4.8 LReference
PTO & Hydraulics
PTO (claimed)20.1 kWReference
PTO (tested)20.1 kWReference
Hydraulic system19.0 LReference
Typeopen centerReference
Capacity19.0 LReference
Pressure137.3 barReference
Rear TypeIReference
Rear lift1011 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1890Reference
Power at rated PTO speed17.7 kWReference
Capacities
Fuel45.4 LReference
Dimensions
Weight1456 kgReference
Front tire5x16Reference
Rear tire10/12.4-28Reference
Ag front5x16Reference
Ag rear10/12.4-28Reference
Ag front4x15Reference
Ag front4.5x16Reference
Ag front5.5x16Reference
Ag rear8x24Reference
Ag rear9.5-9x24Reference
Ag rear11.2/10x24Reference
Ag rear10x36 (High Clearance)Reference
Length276 cmReference
Length302 cmReference
Length251 cmReference
Width160 cmReference
Width1419 cmReference
Width135 cmReference
Width86 cmReference
Height (steering wheel)139 cmReference
Height (steering wheel)130 cmReference
Operating weight1456 kgReference
Ballasted weight2122 kgReference
Ground clearance34 cmReference
Ground clearance60 cmReference
Test results
Diesel 8-speed 2WDOctober 7 - 21, 1966Link: Nebraska Tractor Test 949 fileReference
PTO performanceReference
Fuel use7.2 l/hourReference
Fuel use6.4 l/hourReference
Drawbar performanceReference
Gear 5 used for power test.Reference
Max pull1563 kgReference
Gear 3 used for pull test.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
