Tractor · 2002Unverified

Massey Ferguson 1335

Name: Massey Ferguson 1335
Brand: Massey Ferguson

Massey Ferguson 1335 — Compact Utility tractor · 35 hp. Reference specifications; pending source verification.

The Massey Ferguson 1335 is a tractor with a rated power output of 35 hp, situated at the lower end of its class in terms of power. This model was manufactured from 2002 to 2004. It features a 4-cylinder electric liquid-cooled engine, coupled with four-wheel drive and a hydrostatic transmission. The tractor's operating weight is listed as 1139 kg, with a suitable operating area of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

35 hp

Weight

1139 kg

Catalogue coverage

Variants represented

Richest spec table

42 rows

Recorded power

35 hp

Recorded weight

1139 kg

Transmissions

12-speed mechanical shuttle

Production years

2002-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Mitsubishi 4-cylReference

Fuel tank29.1 LReference

Engine26.1 kWReference

MitsubishiReference

4-cylinderReference

liquid-cooledReference

Power26.1 kWReference

Rated RPM3000Reference

Torque85.0 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed mechanical shuttleReference

Typemechanical shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

Valves2Reference

Pump flow29.9 lpmReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Mid PTO1000Reference

Front PTO2000Reference

Dimensions

Wheelbase163 cmReference

Weight1139 kgReference

Front tire7.00-12Reference

Rear tire320/70R20Reference

Standard tires (ag)Front: 7.00-12. Rear: 320/70R20Reference

Optional tires (ag)Front: 7.00-12. Rear: 11.2R20Reference

Optional tires (ag)Front: 210/80R16. Rear: 11.2R24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear38x14.00-20Reference

Length268 cmReference

Height (steering wheel)123 cmReference

Height (hood)114 cmReference

Ground clearance34 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
