Tractor · 2002Unverified

Massey Ferguson 1345

Name: Massey Ferguson 1345
Brand: Massey Ferguson

Massey Ferguson 1345 — Compact Utility tractor · 42 hp. Reference specifications; pending source verification.

The Massey Ferguson 1345 is a compact tractor model, rated at 42 horsepower, which falls within the lower power range of its class. It was produced from 2002 to 2004. The tractor is equipped with a 4-cylinder turbocharged electric liquid-cooled engine, transmitting power through a hydrostatic transmission to its four-wheel drive system. Its listed operating weight is 1010 kilograms and is suitable for tasks involving up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

42 hp

Weight

1010 kg

Catalogue coverage

Variants represented

Richest spec table

45 rows

Recorded power

42 hp

Recorded weight

1010 kg

Transmissions

12-speed synchro shuttle

Production years

2002-2004

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Steeringhydrostatic powerReference

Mechanical wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Mitsubishi 4-cylReference

Fuel tank29.1 LReference

Engine31.3 kWReference

MitsubishiReference

wastegate turbochargedReference

4-cylinderReference

liquid-cooledReference

Power31.3 kWReference

Rated RPM3000Reference

Torque115.0 NmReference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed synchro shuttleReference

Typesynchro shuttleReference

Gears12 forward and reverseReference

PTO & Hydraulics

Valves2Reference

Pump flow29.9 lpmReference

Rear PTOindependentReference

Rear PTO Type540/1000Reference

Mid PTO1000Reference

Front PTO2000Reference

Dimensions

Wheelbase169 cmReference

Weight1010 kgReference

Front tire7.50-16Reference

Rear tire360/70R24Reference

Standard tires (ag)Front: 7.50-16. Rear: 360/70R24Reference

Optional tires (ag)Front: 7.00-12. Rear: 320/70R20Reference

Optional tires (ag)Front: 7.50-16. Rear: 12.4R24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf front31x13.50-15Reference

Lawn/turf rear38x14.00-20Reference

Lawn/turf rear44x18.00-20Reference

Length302 cmReference

Height (steering wheel)130 cmReference

Height (hood)119 cmReference

Ground clearance38 cmReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
