Tractor · 2002Unverified

Massey Ferguson 1429

Name: Massey Ferguson 1429
Brand: Massey Ferguson

Massey Ferguson 1429 — Compact Utility tractor · 28 hp. Reference specifications; pending source verification.

The Massey Ferguson 1429 is a tractor with a rated power output of 28 hp, classifying it as a lighter model within its category. Produced from 2002 to 2005, this tractor features a 3-cylinder diesel liquid-cooled engine and four-wheel drive with a power-shuttle transmission. Its listed operating weight is 1240 kg, making it suitable for operations covering up to 200 ac.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Weight

1240 kg

Catalogue coverage

Variants represented

Richest spec table

85 rows

Recorded power

28 hp

Recorded weight

1240 kg

Transmissions

8-speed

Production years

2002-2005

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Original price$18,000Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS. Soft-side weather cab optional.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Fuel tank29.9 LReference

Engine (gross)21.2 kWReference

IsekiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

EmissionsTier 2Reference

Power (gross)21.2 kWReference

Fuel systemindirect injectionReference

Rated RPM2500Reference

Starter volts12Reference

Transmission

8-speedReference

TransmissionSynchroShuttleReference

Gears8 forward and reverseReference

Clutchdry discReference

TransmissionPowerShuttleReference

Clutchwet discReference

PTO & Hydraulics

PTO (claimed)17.2 kWReference

Typeopen centerReference

Pressure146.9 barReference

Pump flow28.0 lpmReference

Total flow44.3 lpmReference

Steering flow16.3 lpmReference

Rear TypeIReference

Controlposition and response control, draft control optionalReference

Rear lift (at ends)1250 kgReference

Rear Armstelescopic link ends and stabilizersReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase173 cmReference

Weight1240 kgReference

Rear tire11.2-24Reference

Ag rear11.2-24Reference

Industrial front15-19.5Reference

Length308 cmReference

Width139 cmReference

Height (ROPS)217 cmReference

Height (Folded ROPS)177 cmReference

Front tread108 cmReference

Rear tread109 to 141 cmReference

Massey Ferguson 1429 attachments

72" mid-mount mower deckReference

snowblowerReference

bladeReference

front-end loaderReference

backhoeReference

1429 Serial Numbers

2002LF0001Reference

2003MF0001Reference

2004NF0001Reference

2005P0001Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

72" mid-mount mower deckReference

SnowblowerReference

BladeReference

Front-end loaderReference

BackhoeReference

The Massey Ferguson 1429 was advertised as compatible with 60-inch rear rotary mowers, 72-inch rear finish mowers, 72-inch box blades, and 60-inch tillers.Reference

72" Mower deck

Typemid-mount Massey Ferguson 1432Reference

Type3-bladeReference

Cutting width182 cmReference

Overall width228 cmReference

Cut height5 to 10 cmReference

Cut positions5Reference

Massey Ferguson 1480 Backhoe

Backhoe typeMassey Ferguson 1480 BackhoeReference

Digging depth254 cmReference

Reach from pivot322 cmReference

Bucket Rotation165°Reference

Swing Arc180°Reference

Bucket force1886 kgReference

Dipperstick force1179 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
