Tractor · 2002Unverified
Massey Ferguson 1455
Massey Ferguson 1455 — Compact Utility tractor · 55 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
55 hp
Weight
1719 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Two- or four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Variants
1455Vvalue modelReference
Engine
Iseki 2.8L 4-cyl dieselReference
Fuel tank48.1 LReference
Engine (gross)41.2 kWReference
IsekiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement2.8 LReference
EmissionsTier 2Reference
Power (gross)41.2 kWReference
Fuel systemindirect injectionReference
Rated RPM2500Reference
Starter volts12Reference
Transmission
16-speedReference
8-speedReference
12-speedReference
TransmissionPowerShuttleReference
Gears16 forward and reverseReference
Clutchwet discReference
TransmissionSynchroShuttleReference
Gears8 forward and reverseReference
Clutchdry discReference
Available on the two-wheel drive 1455V.Reference
Gears12 forward and reverseReference
Available on the four-wheel drive 1455V.Reference
PTO & Hydraulics
PTO (claimed)34.0 kWReference
Typeopen centerReference
Pressure156.9 barReference
Pump flow43.1 lpmReference
Total flow65.5 lpmReference
Steering flow22.3 lpmReference
Rear TypeIReference
Controlposition and draft controlReference
Rear lift (at ends)1399 kgReference
Rear Armstelescopic link ends and stabilizersReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540Reference
Dimensions
Wheelbase200 cmReference
Weight1719 kgReference
Rear tire13.6-28Reference
Ag rear13.6-28Reference
Ag rear14.9-28Reference
Industrial rear17.5L-24Reference
Length347 cmReference
Width164 cmReference
Height (ROPS)250 cmReference
Height (Folded ROPS)191 cmReference
Front tread138 cmReference
Rear tread144 to 157 cmReference
Massey Ferguson 1455 attachments
front-end loaderReference
backhoeReference
1455 Serial Numbers
2002LW0001Reference
2003MW0001Reference
2004NW0001Reference
2005P0001Reference
2002LX0001Reference
2003MX0001Reference
2004NX0001Reference
FAQ: How to read a serial number table.Reference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
The Massey Ferguson 1455 was advertised as compatible with 72-inch rear rotary mowers, 84-inch rear finish mowers, 84-inch box blades, and 72-inch tillers.Reference
Massey Ferguson 1475 Backhoe
Backhoe typeMassey Ferguson 1475 BackhoeReference
Digging depth228 cmReference
Reach from pivot284 cmReference
Bucket Rotation165°Reference
Swing Arc180°Reference
Bucket force1474 kgReference
Dipperstick force861 kgReference
Massey Ferguson 1480 Backhoe
Backhoe typeMassey Ferguson 1480 BackhoeReference
Digging depth254 cmReference
Reach from pivot322 cmReference
Bucket Rotation165°Reference
Swing Arc180°Reference
Bucket force1886 kgReference
Dipperstick force1179 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
