Tractor · 1964Unverified
Massey Ferguson 150
Massey Ferguson 150 · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Max power
24.7 kW
Weight
2179 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Built in Detroit, Michigan, USAReference
Original price was $5,693 in 1975Reference
Two-wheel driveReference
Power steeringReference
Differential mechanical disc brakesReference
Open operator station. Two-post ROPS and canopy optional.Reference
Variants
Standardfixed wide-frontReference
Wide Row Cropadjustable wide-frontReference
Tricyclenarrow row-crop frontReference
Engine
Perkins 2.5L 3-cyl dieselReference
Continental 2.4L 4-cyl gasolineReference
Perkins 2.5L 3-cyl gasolineReference
Engine33.9 kWReference
Drawbar (claimed)24.6 kWReference
Plows3Reference
Drawbar (tested)24.7 kWReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power33.9 kWReference
Air cleaneroil bathReference
Compression17.4:1Reference
Rated RPM2000Reference
Torque155.9 NmReference
Torque RPM1200Reference
Starter volts12Reference
Oil capacity6.0 LReference
Coolant capacity9.9 LReference
Continental Z-145Reference
gasolineReference
4-cylinderReference
Displacement2.4 LReference
Bore/Stroke86 x 103 mmReference
Compression7.1:1Reference
Torque169.5 NmReference
Perkins AG3.152Reference
Compression7.5:1Reference
Power at rated engine speed28.2 kWReference
Max power24.7 kWReference
Transmission
8-speedReference
12-speed partial power shiftReference
6-speed gearReference
Gears8 forward and 2 reverseReference
Clutchdry plateReference
TransmissionMulti-PowerReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Three speeds plus reverse with high and low range. Multi-Power provides high and low power shift in each gear.Reference
TypegearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)28.3 kWReference
PTO (tested)28.2 kWReference
Hydraulic system30.3 LReference
Capacity30.3 LReference
Total flow18.2 lpmReference
Rear TypeIReference
Rear PTOliveReference
Rear PTOindependent (optional)Reference
Rear PTO Type540Reference
Power at rated PTO speed26.4 kWReference
Capacities
Fuel70.0 LReference
Dimensions
Wheelbase205 cmReference
Wheelbase214 cmReference
Weight2179 kgReference
Front tire6.00-16Reference
Rear tire13.6/12x28Reference
Ag front6.00-16Reference
Ag front5.5-16 (tricycle)Reference
Ag rear13.6/12x28 (standard front)Reference
Ag rear12.4/11-38Reference
Length334 cmReference
Width161 cmReference
Height (steering wheel)165 cmReference
Operating weight2179 kgReference
Ballasted weight2996 kgReference
Ground clearance32 cmReference
Ground clearance38 cmReference
Front tread121 to 182 cmReference
Rear tread121 to 193 cmReference
Rear tread132 to 182 cmReference
Massey Ferguson 150 attachments
front-end loaderReference
150 Serial Numbers
Location:Below instrument panelReference
1964642000003Reference
1965642000859Reference
1966642003946Reference
1967642005474Reference
19679A1000Reference
19689A39836Reference
19699A63158Reference
19709A87325Reference
19719A107597Reference
19729A128141Reference
19739A152025Reference
19749A179544Reference
19759A207681Reference
FAQ: How to read a serial number table.Reference
Test results
Diesel 12-speed 2WDMay 25 - June 9, 1965Link: Nebraska Tractor Test 901 fileReference
PTO performanceReference
Fuel use7.9 l/hourReference
Fuel use7.2 l/hourReference
Drawbar performanceReference
Fuel use8.3 l/hourReference
Gear 1HL used for power test.Reference
Max pull2171 kgReference
Gear 2LH used for pull test.Reference
Speeds
With 13.6/12-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
