Tractor · 2005Unverified
Massey Ferguson 1519
Massey Ferguson 1519 — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
20 hp
Weight
1477 to 1510 pounds
Hover a source tag to verify
Overview
DistributorMassey Ferguson (a part of AGCO)Reference
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Mechanical wet disc brakesReference
Two-post folding ROPS.Reference
Variants
TM3200similar Iseki modelReference
Engine
Iseki 1.1L 3-cyl dieselReference
Fuel tank25.0 LReference
Engine14.5 kWReference
Iseki E3112Reference
dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.1 LReference
Bore/Stroke78 x 78 mmReference
Power14.5 kWReference
Air cleanerdryReference
Rated RPM2500Reference
Firing order1-3-2Reference
StarterelectricReference
Starter volts12Reference
Transmission
6-speed gearReference
hydrostaticReference
Gear Weight669 kgReference
TypegearReference
Gears6 forward and 2 reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverse (2-range)Reference
PTO & Hydraulics
Typeopen centerReference
Pump flow19.7 lpmReference
Rear TypeIReference
Rear lift539 kgReference
Gear Rear PTOliveReference
Hydro Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOliveReference
Mid PTO Type2000Reference
Dimensions
Wheelbase151 cmReference
Weight1477 to 1510 poundsReference
Front tire5.00-12Reference
Rear tire8-18Reference
Ag front5.00-12Reference
Ag rear8-18Reference
Lawn/turf front20.5x8.00-10Reference
Lawn/turf rear29x12.00-15Reference
Length267 cmReference
Width106 cmReference
Height (ROPS)231 cmReference
Hydro Weight684 kgReference
Ground clearance23 cmReference
Electrical
GroundnegativeReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
