Tractor · 2007Unverified

Massey Ferguson 1529

Name: Massey Ferguson 1529
Brand: Massey Ferguson

Massey Ferguson 1529 — Model year 2007-20102011-2014 · 28 hp. Reference specifications; pending source verification.

The Massey Ferguson 1529 is a compact tractor, rated at 28 hp, suitable for smaller-scale operations. Manufactured from 2007 to 2014, it features a 3-cylinder diesel liquid-cooled engine, which powers a four-wheel drive system with an 8-speed gearbox. The tractor has a listed weight of 1169 kg and is designed for use on land areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

28 hp

Max power

28.4 hp

Weight

1169 kg

Catalogue coverage

Variants represented

Richest spec table

114 rows

Recorded power

28 hp

Recorded weight

1169 kg

Transmissions

8-speed

Production years

2007-2014

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

DistributorMassey FergusonReference

ManufacturerIsekiReference

Compact Utility tractorReference

Built in Matsuyama, JapanReference

Original price was $13,468 in 2008Reference

Four-wheel driveReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Engine (gross)21.2 kWReference

Engine (net)20.6 kWReference

IsekiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power (net)20.6 kWReference

Power (gross)21.2 kWReference

Air cleanerdryReference

Rated RPM2500Reference

Torque91.3 NmReference

Torque RPM1500Reference

StarterelectricReference

Starter volts12Reference

Oil capacity3.1 LReference

Coolant capacity6.2 LReference

Fuel TypedieselReference

No of Cylinders3 cylinderReference

Rated engine speed2,500 RPMReference

Engine torque at rated speed30.5 kgReference

Bore and stroke3.43x3.31 inchesReference

Cooling systemliquid-cooledReference

Transmission

8-speedReference

TransmissionSynchroShuttleReference

Gears8 forward and reverseReference

Oil capacity34.1 LReference

Transmission TypeMechanical ShuttleReference

Wheel Drive4WDReference

Clutchelectro-hydraulicReference

PTO & Hydraulics

PTO (claimed)17.3 kWReference

Typeopen centerReference

Valves1 or 2Reference

Pump flow28.0 lpmReference

Total flow40.9 lpmReference

Steering flow12.9 lpmReference

Rear TypeIReference

Rear lift (at ends)1099 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Mid PTO Type2000Reference

Capacities

Fuel31.4 LReference

Front axle4.8 LReference

Max capacity2399 kgReference

Capacity91.4 ciReference

Fuel tank34.8 LReference

Crankcase oil volume3.3 qtsReference

Dimensions

Wheelbase169 cmReference

Weight1169 kgReference

Front tire7x14Reference

Rear tire11.2x24Reference

Standard tires (ag)Front: 7x14. Rear: 11.2x24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear41x14.00-20Reference

Industrial front25x8.50-14Reference

Industrial rear15.00x19.5Reference

Length306 cmReference

Width147 cmReference

Height (ROPS)246 cmReference

Ground clearance26 cmReference

Front tread83 cmReference

Rear tread109 cmReference

Shipping1169 kgReference

Max front axle1200 kgReference

Max rear axle1300 kgReference

Massey Ferguson 1529 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps40Reference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Massey Ferguson 1570 Backhoe

Backhoe typeMassey Ferguson 1570 BackhoeReference

Digging depth198 cmReference

Reach from pivot259 cmReference

Bucket force1088 kgReference

Dipperstick force657 kgReference

General

Make & ModelIsekiReference

Rollover protective structureTwo-post folding ROPSReference

Country of manufacturerJapanReference

Power

Max Power28.4 hpReference

Rated Power27.6 hpReference

PTO

PTO Power23.2 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTOAvailableReference

Mid PTO RPM2,000 RPMReference

Steering & brakes

Brakeswet discReference

Steering typepowerReference

Hydraulics

Pump Rated Output (total)11.5 gpmReference

Hydraulics Typeopen centerReference

Remote Valves0 to 2 ValvesReference

Steering & Implements flow3.4 gpm (8.1 gpm)Reference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity1,100 kgReference

Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over ROPS246.4 cmReference

Overall Length306.6 cmReference

Overall Width147.6 cmReference

Overall weight1,205.2 kgReference

Wheels & tyres

Rear wheel tread range109.2 cmReference

Front Wheel tread range83.8 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
