Tractor · Unverified

Massey Ferguson 152S

Name: Massey Ferguson 152S
Brand: Massey Ferguson

Massey Ferguson 152S — Utility tractor · 45 hp. Reference specifications; pending source verification.

The Massey Ferguson 152S is a tractor with a rating of approximately 45 hp, positioning it in the lower power range of its class. It features a 3-cylinder diesel liquid-cooled engine and a two-wheel drive system with an 8-speed gearbox. The tractor has a listed operating weight of 1754 kg, and is suitable for use on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

45 hp

Weight

1754 kg

Catalogue coverage

Variants represented

Richest spec table

55 rows

Recorded power

45 hp

Recorded weight

1754 kg

Transmissions

8-speed synchromesh

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Utility tractorReference

Two-wheel driveReference

Manual steeringReference

Wet disc brakesReference

Open operator station.Reference

Variants

152SutilityReference

152VvineyardReference

Engine

Perkins 2.5L 3-cyl dieselReference

Fuel tank48.1 LReference

Engine35.0 kWReference

Perkins AD3.152Reference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power35.0 kWReference

Fuel systemdirect injectionReference

Air cleanerdual dry elementsReference

Pre-heatingthermostartReference

Compression16.5:1Reference

Rated RPM2250Reference

Torque169.5 NmReference

Torque RPM1400Reference

StarterelectricReference

Starter volts12Reference

Oil capacity6.6 LReference

Coolant capacity11.3 LReference

Transmission

8-speed synchromeshReference

TypesynchromeshReference

Gears8 forward and 2 reverseReference

Oil capacity39.0 LReference

Four gears, plus reverse, with low and high range shift.Reference

PTO & Hydraulics

PTO (claimed)33.3 kWReference

PTO (claimed)28.9 kWReference

Pressure172.4 barReference

Pump flow16.7 lpmReference

Rear TypeII/IReference

Controlposition and draft controlReference

Rear lift (at ends)1834 kgReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Engine RPM540@1684Reference

Dimensions

Wheelbase190 cmReference

Weight1754 kgReference

Front tire6.00-16Reference

Rear tire11.2/10-28Reference

Ag front6.00-16Reference

Ag rear11.2/10-28Reference

Length304 cmReference

Width124 cmReference

Height (steering wheel)137 cmReference

Front tread111 to 170 cmReference

Rear tread101 to 152 cmReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
