Tractor · Unverified
Massey Ferguson 152S
Massey Ferguson 152S — Utility tractor · 45 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
45 hp
Weight
1754 kg
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Utility tractorReference
Two-wheel driveReference
Manual steeringReference
Wet disc brakesReference
Open operator station.Reference
Variants
152SutilityReference
152VvineyardReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank48.1 LReference
Engine35.0 kWReference
Perkins AD3.152Reference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power35.0 kWReference
Fuel systemdirect injectionReference
Air cleanerdual dry elementsReference
Pre-heatingthermostartReference
Compression16.5:1Reference
Rated RPM2250Reference
Torque169.5 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity11.3 LReference
Transmission
8-speed synchromeshReference
TypesynchromeshReference
Gears8 forward and 2 reverseReference
Oil capacity39.0 LReference
Four gears, plus reverse, with low and high range shift.Reference
PTO & Hydraulics
PTO (claimed)33.3 kWReference
PTO (claimed)28.9 kWReference
Pressure172.4 barReference
Pump flow16.7 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)1834 kgReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Engine RPM540@1684Reference
Dimensions
Wheelbase190 cmReference
Weight1754 kgReference
Front tire6.00-16Reference
Rear tire11.2/10-28Reference
Ag front6.00-16Reference
Ag rear11.2/10-28Reference
Length304 cmReference
Width124 cmReference
Height (steering wheel)137 cmReference
Front tread111 to 170 cmReference
Rear tread101 to 152 cmReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
