The Massey Ferguson 152V is a tractor with a rated output of 50 hp, categorising it as one of the more compact options within its class. It is powered by a 3-cylinder diesel liquid-cooled engine, which drives through an 8-speed gearbox. The tractor's listed weight is 1700 kg, making it suitable for jobs covering up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
50 hp
Weight
1700 kg
Catalogue coverage
Variants represented
2
Richest spec table
44 rows
Recorded power
50 hp
Recorded weight
1700 kg
Transmissions
8-speed gear
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Open operator station.Reference
Variants
152SutilityReference
152VvineyardReference
Engine
Perkins 2.5L 3-cyl dieselReference
Fuel tank48.1 LReference
Engine (gross)37.5 kWReference
Engine (net)34.6 kWReference
Perkins 3-152SReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement2.5 LReference
Bore/Stroke91 x 127 mmReference
Power (net)34.6 kWReference
Power (gross)37.5 kWReference
Rated RPM2250Reference
Torque176.0 NmReference
Torque RPM1400Reference
StarterelectricReference
Starter volts12Reference
Transmission
8-speed gearReference
TypegearReference
Gears8 forward and 2 reverseReference
PTO & Hydraulics
Pump flow36.0 lpmReference
Rear TypeIReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Dimensions
Wheelbase184 cmReference
Weight1700 kgReference
Front tire4.50-16Reference
Rear tire11.2-28Reference
Ag front4.50-16Reference
Ag rear11.2-28Reference
Ag front4.00-15Reference
Ag front6.00-16Reference
Ag rear12.4-28Reference
Length278 cmReference
Width109 cmReference
Height (steering wheel)136 cmReference
Front tread82 to 113 cmReference
Rear tread73 to 140 cmReference
Speeds
With 11.2-28 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
