Tractor · 2007Unverified
Massey Ferguson 1532
Massey Ferguson 1532 — Model year 2007-20102011-2014 · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
1174 kg
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Original price$14,182 (2008 gear )Reference
Original price$14,962 (2008 shuttle )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)24.2 kWReference
Engine (net)23.5 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (net)23.5 kWReference
Power (gross)24.2 kWReference
Rated RPM2600Reference
Torque94.1 NmReference
Torque RPM1500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.7 LReference
Coolant capacity5.9 LReference
Transmission
9-speed gearReference
8-speedReference
TypegearReference
Gears9 forward and 3 reverseReference
Oil capacity34.1 LReference
TransmissionSynchroShuttleReference
Gears8 forward and reverseReference
PTO & Hydraulics
PTO (claimed)19.8 kWReference
Typeopen centerReference
Valves1 or 2Reference
Pump flow29.1 lpmReference
Total flow42.8 lpmReference
Steering flow13.6 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1099 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type2000Reference
Capacities
Fuel31.4 LReference
Front axle4.8 LReference
Max capacity2399 kgReference
Dimensions
Wheelbase169 cmReference
Weight1174 kgReference
Front tire7x14Reference
Rear tire11.2x24Reference
Standard tires (ag)Front: 7x14. Rear: 11.2x24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front25x8.50-14Reference
Industrial rear15.00x19.5Reference
Length305 cmReference
Width147 cmReference
Height (ROPS)246 cmReference
Ground clearance26 cmReference
Front tread83 cmReference
Rear tread109 cmReference
Shipping1174 kgReference
Max front axle1200 kgReference
Max rear axle1300 kgReference
Massey Ferguson 1532 attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps40Reference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson 1570 Backhoe
Backhoe typeMassey Ferguson 1570 BackhoeReference
Digging depth198 cmReference
Reach from pivot259 cmReference
Bucket force1088 kgReference
Dipperstick force657 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
