Tractor · 2005Unverified
Massey Ferguson 1533
Massey Ferguson 1533 — Model year 2005-20102011-2014 · 33 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
33 hp
Weight
3025 to 3384 pounds
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIsekiReference
Compact Utility tractorReference
Built in Matsuyama, JapanReference
Original price$15,426 (2008 sync-shuttle ROPS )Reference
Original price$25,538 (2008 hydrostatic Cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 1.5L 3-cyl dieselReference
Engine (gross)24.6 kWReference
Engine (net)23.9 kWReference
IsekiReference
dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (net)23.9 kWReference
Power (gross)24.6 kWReference
Air cleanerdryReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Oil capacity4.7 LReference
Coolant capacity6.7 LReference
Transmission
8-speedReference
hydrostaticReference
12-speedReference
TransmissionSynchroShuttleReference
Gears8 forward and reverseReference
Oil capacity31.0 LReference
Available with platform onlyReference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
TransmissionPowerShuttleReference
Gears12 forward and reverseReference
PTO & Hydraulics
Gear PTO (claimed)19.4 kWReference
Hydro PTO (claimed)18.3 kWReference
Typeopen centerReference
Valves2Reference
Pump flow34.4 lpmReference
Total flow53.0 lpmReference
Total flow57.2 lpmReference
Steering flow18.5 lpmReference
Steering flow22.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1270 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOoptionalReference
Mid PTO Type2000Reference
Capacities
Fuel40.1 LReference
Front axle7.5 LReference
Max capacity3000 kgReference
Dimensions
Wheelbase177 cmReference
Weight3025 to 3384 poundsReference
Front tire8-16Reference
Rear tire12.4-24Reference
Standard tires (ag)Front: 8-16. Rear: 12.4-24Reference
Optional tires (ag)Front: 8-16. Rear: 13.6-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Lawn/turf frontLSW305 R343 LSW430Reference
Lawn/turf rearLSW610 R470 LSW430Reference
Industrial front10-16.5Reference
Industrial rear14.9-24Reference
Industrial front25x8.5-14Reference
Industrial rear15x19.5Reference
Length307 cmReference
Width157 cmReference
Height221 cmReference
Ground clearance35 cmReference
Front tread112 cmReference
Rear tread118 cmReference
ROPS1372 kgReference
Cab1534 kgReference
Max front axle1799 kgReference
Max rear axle1799 kgReference
Massey Ferguson 1533 attachments
snowblowerReference
bladeReference
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Attachment overview
SnowblowerReference
BladeReference
Front-end loaderReference
BackhoeReference
Massey Ferguson 1575 Backhoe
Backhoe typeMassey Ferguson 1575 BackhoeReference
Digging depth228 cmReference
Reach from pivot284 cmReference
Swing Arc180°Reference
Bucket force1474 kgReference
Dipperstick force861 kgReference
Massey Ferguson 1580 Backhoe
Backhoe typeMassey Ferguson 1580 BackhoeReference
Digging depth254 cmReference
Reach from pivot322 cmReference
Swing Arc180°Reference
Bucket force1886 kgReference
Dipperstick force1179 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
