Tractor · 2009Unverified

Massey Ferguson 1660

Massey Ferguson 1660 — Compact Utility tractor · 60 hp. Reference specifications; pending source verification.

The Massey Ferguson 1660 is a tractor with a rated power output of approximately 60 hp, positioning it at the lower end of its class. It was manufactured between 2009 and 2013 and features a 4-cylinder diesel liquid-cooled engine paired with four-wheel drive and a powershift transmission. The operating weight of this model ranges from 4079 to 4453 pounds. It is suitable for use in operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power
60 hp
Max power
60 hp
Weight
4079 to 4453 pounds

Catalogue coverage

Variants represented
2
Richest spec table
115 rows
Recorded power
60 hp
Transmissions
12-speed
Production years
2009-2013
Verified variants
0

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference
Compact Utility tractorReference
Original price$25,704 (2009 PowerShuttle ROPS )Reference
Original price$32,042 (2009 DynaQPS Cab )Reference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Flat operator platform with folding ROPS. Optional cab with heat and air-conditioning.Reference

Engine

Iseki 3.0L 4-cyl dieselReference
Fuel tank50.0 LReference
Engine (gross)44.7 kWReference
IsekiReference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.0 LReference
EmissionsTier IV InterimReference
Power (gross)44.7 kWReference
Air cleanerdryReference
Rated RPM2500Reference
StarterelectricReference
Starter volts12Reference
Oil capacity8.0 LReference
Coolant capacity7.6 LReference
Fuel TypedieselReference
No of Cylinders4 cylinderReference
Rated engine speed2,500 RPMReference
Emissions complianceTier IV InterimReference
Cooling systemliquid-cooledReference

Transmission

12-speedReference
TransmissionPowerShuttleReference
Gears12 forward and reverseReference
Oil capacity38.0 LReference
Available only on platform models.Reference
TransmissionDynaQPSReference
The DynaQPS tranmission provides partial power shift in addition to a power shuttle. Three ranges, with four power shifts in each range. DynaQPS available only on cab-equipped models.Reference
Transmission TypePower ShuttleReference
forward and reverse optionsPowerShuttle : 12 F and 12 R | DynaQPS : 12 F and 12 RReference
Wheel Drive4WDReference

PTO & Hydraulics

PTO (claimed)34.6 kWReference
Typeopen centerReference
Valves0 to 3Reference
Pump flow47.3 lpmReference
Total flow74.2 lpmReference
Steering flow25.7 lpmReference
Rear TypeIReference
Controlposition controlReference
Rear lift (at ends)1579 kgReference
Rear PTOindependentReference
Clutchelectro-hydraulicReference
Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase199 cmReference
Weight4079 to 4453 poundsReference
Front tire9.5x16Reference
Rear tire16.9x26Reference
Standard tires (ag)Front: 9.5x16. Rear: 16.9x26Reference
Lawn/turf front27x12LL-15Reference
Lawn/turf rearLSW570x648Reference
Lawn/turf front27x10.50-15Reference
Lawn/turf rear44x18.00-20Reference
Industrial front12-16.5Reference
Industrial rear18.4-24Reference
Length341 cmReference
Width180 cmReference
Height (ROPS)264 cmReference
Height (cab)233 cmReference
Ground clearance39 cmReference
Front tread138 cmReference
Rear tread146 cmReference
ROPS Shipping1850 kgReference
Cab Shipping2019 kgReference
Max front axle2100 kgReference
Max rear axle2100 kgReference

Massey Ferguson 1660 attachments

front-end loaderReference
backhoeReference

Electrical

GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference

Attachment overview

Front-end loaderReference
BackhoeReference

Massey Ferguson CB25 Backhoe

Backhoe typeMassey Ferguson CB25 BackhoeReference
Digging depth313 cmReference
Bucket force1433 kgReference
Dipperstick force1132 kgReference

Capacities

Max capacity3800 kgReference
Capacity180.4 ciReference
Crankcase oil volume8.5 qtsReference

General

Make & ModelMassey FergusonReference
SCV controlJoystickReference
Rear tread spacing146.1 cmReference
Rollover protective structureFlat operator platform with folding ROPS.Reference

Power

Max Power60 hpReference

PTO

PTO Power46.4 hpReference
Rear PTO PowerAvailableReference
Rear PTO RPM540 RPMReference

Steering & brakes

Brakeswet discReference
Steering typepowerReference

Hydraulics

Pump Rated Output (total)19.6 gpmReference
Hydraulics Typeopen centerReference
Remote Valves0 to 3 ValvesReference
Steering & Implements flow6.8 gpm (12.5 gpm)Reference
Rear Hitch category (SAE designation)Category IReference
Rear Hitch maximum lift capacity1,579.9 kgReference
Rear Hitch Sensing Typeposition controlReference

Dimensions & weight

Height Over Cab233.4 cmReference
Height Over ROPS264.4 cmReference
Overall Length341.9 cmReference
Overall Width180.1 cmReference
Overall weight1,850.2 kgReference

Wheels & tyres

Rear Wheel Type16.9x26Reference
Front Wheel Type9.5x16Reference
Front Wheel tread range138.4 cmReference

Operator station

Cab AvailabilityAvailableReference
Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
