Tractor · 2013Unverified

Massey Ferguson 1726E

Name: Massey Ferguson 1726E
Brand: Massey Ferguson

Massey Ferguson 1726E — Compact Utility tractor · 20 hp. Reference specifications; pending source verification.

The Massey Ferguson 1726E is a tractor with a rated power of 20 hp, positioning it at the lighter end of its class. It was introduced to the market in 2013 and is powered by a 3-cylinder diesel liquid-cooled engine, paired with a four-wheel drive system and hydrostatic transmission. The tractor's operating weight is specified as 2600 to 2657 pounds, and it is capable of operating on areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Max power

24 hp

Weight

2600 to 2657 pounds

Catalogue coverage

Variants represented

Richest spec table

82 rows

Recorded power

20 hp

Recorded weight

1179 kg

Transmissions

9-speed gear

Production years

2013-1700

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Compact Utility tractorReference

Four-wheel driveReference

Final drivesbull gearReference

Differential lockrear standardReference

Power steeringReference

Wet disc brakesReference

Two-post foldable ROPS.Reference

Engine

Shibaura 1.5L 3-cyl dieselReference

Fuel tank37.9 LReference

Engine17.9 kWReference

Shibaura N843T-FReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke84 x 90 mmReference

EmissionsTier IVReference

Emission controlinternal exhaust-gas recirculatio (iEGR)Reference

Power17.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,600 RPMReference

Emissions complianceTier IV internal exhaust-gas recirculatio (iEGR)Reference

Bore and stroke3.307x3.543 inchesReference

Cooling systemliquid-cooledReference

Transmission

9-speed gearReference

hydrostaticReference

Gear Weight1179 kgReference

TypegearReference

Gears9 forward and 3 reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypeGearReference

forward and reverse optionsGear - 9F and 3R | hydrostatic infinite - F and infinite RReference

Wheel Drive4WDReference

Rear Axle Drive Typebull gearReference

PTO & Hydraulics

Gear PTO (claimed)15.2 kWReference

Hydro PTO (claimed)14.3 kWReference

Typeopen center gear pumpReference

SCV flow25.4 lpmReference

Total flow39.7 lpmReference

Steering flow14.4 lpmReference

Rear TypeIReference

Rear lift (at ends)1000 kgReference

Rear lift (at 24"/610mm)724 kgReference

Rear PTOtransmissionReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase167 cmReference

Weight2600 to 2657 poundsReference

Length294 cmReference

Width133 cmReference

Height (ROPS)247 cmReference

Height (ROPS)162 cmReference

Hydro Weight1205 kgReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelMassey Ferguson (a part of AGCO)Reference

Cruise controlAvailableReference

SCV controlJoystickReference

Rollover protective structureTwo-post foldable ROPSReference

Capacities

Capacity91.3 ciReference

Power

Max Power24 hpReference

PTO

PTO Power20.4 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Steering & brakes

BrakesWet disc brakesReference

Steering typePower steeringReference

Hydraulics

Pump Rated Output (total)10.5 gpmReference

Hydraulics Typeopen center gear pumpReference

Steering & Implements flow3.8 gpmReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch maximum lift capacity1,000.2 kgReference

Dimensions & weight

Height Over ROPS247.9 cmReference

Overall Length294.6 cmReference

Overall Width133.1 cmReference

Overall weight1,205.2 kgReference

Operator station

Cab AvailabilityTRUEReference

Seat SuspensionTRUEReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
