Tractor · 2013Unverified
Massey Ferguson 1740
Massey Ferguson 1740 — Compact Utility tractor · 38 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
38 hp
Weight
3369 to 3704 pounds
Hover a source tag to verify
Overview
DistributorMassey Ferguson (a part of AGCO)Reference
ManufacturerIsekiReference
Compact Utility tractorReference
Four-wheel driveReference
Differential lockmechanical rearReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS, mid-mount or rear available. Cab available with air-conditioning.Reference
Variants
TG6405similar Iseki modelReference
Engine
Iseki 1.5L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine (gross)28.3 kWReference
Iseki E3CDTReference
turbocharged dieselReference
3-cylinderReference
liquid-cooled inlineReference
Displacement1.5 LReference
Bore/Stroke87 x 84 mmReference
Power (gross)28.3 kWReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed mechanical shuttleReference
hydrostaticReference
Typemechanical shuttleReference
Gears12 forward and reverseReference
TypehydrostaticReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Pump flow74.2 lpmReference
Rear TypeIReference
Rear lift1270 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Dimensions
Wheelbase177 cmReference
Weight3369 to 3704 poundsReference
Front tire8.00-16Reference
Rear tire13.6-24Reference
Standard tires (ag)Front: 8.00-16. Rear: 13.6-24Reference
Lawn/turf front212x80D15Reference
Lawn/turf rear355x80D20Reference
Length347 cmReference
Width144 cmReference
Height (ROPS)219 cmReference
ROPS Weight1528 kgReference
Cab Weight1680 kgReference
Ground clearance30 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Battery volts12Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
