Tractor · 2013Unverified

Massey Ferguson 1742

Name: Massey Ferguson 1742
Brand: Massey Ferguson

Massey Ferguson 1742 — Compact Utility tractor · 33 hp. Reference specifications; pending source verification.

The Massey Ferguson 1742 is a tractor with a rating of approximately 33 hp, positioned at the lower end of its class. Produced between 2013 and 2018, this model features a 3-cylinder turbocharged intercooled diesel liquid-cooled engine, paired with a four-wheel drive system and a hydrostatic transmission. Its operating weight ranges from 3638 to 4068 pounds, and it is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

33 hp

Max power

41.6 hp

Weight

3638 to 4068 pounds

Catalogue coverage

Variants represented

Richest spec table

94 rows

Recorded power

33 hp

Recorded weight

1650 kg

Transmissions

12-speed power shuttle

Production years

2013-2018

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Compact Utility tractorReference

Original price was $26,318 in 2018 with shuttle, ROPSReference

Four-wheel driveReference

Final drivesbull gearReference

Wet disc brakesReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Mitsubishi 1.7L 3-cyl dieselReference

Fuel tank54.9 LReference

Engine31.0 kWReference

Mitsubishi K38Reference

turbocharged intercooled dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement1.7 LReference

Bore/Stroke86 x 95 mmReference

EmissionsTier IVReference

Emission controldiesel oxidation catalyst and diesel particulate filterReference

Power31.0 kWReference

Fuel systemhigh-pressure common rail direct injectionReference

Rated RPM2500Reference

StarterelectricReference

Starter volts12Reference

Fuel TypedieselReference

No of Cylinders3 CylinderReference

Rated engine speed2,500 RPMReference

Emissions complianceTier IV diesel oxidation catalyst and diesel particulate filterReference

Bore and stroke3.386x3.74 inchesReference

Cooling systemliquid-cooled inlineReference

Transmission

12-speed power shuttleReference

hydrostaticReference

Typepower shuttleReference

Gears12 forward and reverseReference

Clutchwet discReference

Four synchronized gears in three ranges.Reference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

Transmission TypePower ShuttleReference

Wheel Drive4WDReference

Rear Axle Drive Typebull gearReference

PTO & Hydraulics

PTO (claimed)24.5 kWReference

Typeopen center gear pumpReference

Valves1 to 3Reference

SCV flow43.9 lpmReference

Rear TypeIReference

Controlposition controlReference

Controldraft controlReference

Rear lift (at 24"/610mm)1149 kgReference

Rear PTOindependentReference

Clutchelectro-hydraulicReference

Rear PTO Type540 (1.375)Reference

Mid PTOoptionalReference

Mid PTO Type2000Reference

Dimensions

Wheelbase180 cmReference

Weight3638 to 4068 poundsReference

Ag front8-16:12.4x24Reference

Ag rear8-16:13.6x24Reference

Lawn/turf front27x8.50-15Reference

Lawn/turf rear41x14.00-20Reference

Industrial front10-16.5Reference

Industrial rear17.5L-24Reference

Industrial front250/75R16Reference

Industrial rear400/80R24Reference

Length331 cmReference

Width163 cmReference

Height (cab)231 cmReference

ROPS Weight1650 kgReference

Cab Weight1845 kgReference

Massey Ferguson 1742 attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

General

Make & ModelMassey FergusonReference

Cruise controlAvailableReference

SCV controlJoystickReference

Rollover protective structureTwo-post folding ROPSReference

Capacities

Capacity101 ciReference

Power

Max Power41.6 hpReference

PTO

PTO Power32.8 hpReference

Rear PTO PowerAvailableReference

Rear PTO RPM540 RPMReference

Mid PTO RPM2,000 RPMReference

Steering & brakes

Brakeswet discReference

Hydraulics

Hydraulics Typeopen center gear pumpReference

Remote Valves1 to 3 ValvesReference

Rear Hitch category (SAE designation)Category IReference

Rear Hitch Sensing Typeposition control | draft controlReference

Dimensions & weight

Height Over Cab231.9 cmReference

Overall Length332 cmReference

Overall Width163.1 cmReference

Overall weight1,650.2 kgReference

Wheels & tyres

Rear Wheel Type8-16:13.6x24Reference

Front Wheel Type8-16:12.4x24Reference

Operator station

Cab AvailabilityAvailableReference

Seat SuspensionAvailableReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
