Tractor · 1986Unverified
Massey Ferguson 174S
Massey Ferguson 174S — Orchard/Vineyard tractor · 57 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
57 hp
Weight
2685 to 4995 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Orchard/Vineyard tractorReference
Original price was $19,500 in 1989Reference
Two- or four-wheel driveReference
Final drivesoutboard planetaryReference
Differential lockmechanical rearReference
Power steeringReference
Hydraulic wet disc brakesReference
Open operator station.Reference
Engine
Perkins 3.9L 4-cyl dieselReference
Perkins A4.236Reference
dieselReference
4-cylinderReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Air cleanerdryReference
Pre-heatingthermostartReference
Rated RPM2200Reference
StarterelectricReference
Starter volts12Reference
Oil capacity6.6 LReference
Coolant capacity15.1 LReference
Transmission
12-speed partially synchronizedReference
20-speed creeperReference
Typepartially synchronizedReference
Gears12 forward and 4 reverseReference
Clutch279.4mm dry discReference
Oil capacity37.9 LReference
Four synchronized gears in three ranges, plus reverse range.Reference
TypecreeperReference
Gears20 forward and 8 reverseReference
Clutchdry discReference
PTO & Hydraulics
PTO (claimed)42.5 kWReference
Hydraulic system37.9 LReference
Typeopen centerReference
Capacity37.9 LReference
Rear valves2Reference
Pump flow34.8 lpmReference
Rear TypeII/IReference
Controlposition and draft controlReference
Rear lift (at ends)2399 kgReference
Rear PTOindependentReference
Rear PTO Type540/1000 (1.375)Reference
Capacities
Fuel53.0 LReference
Dimensions
2WD Wheelbase207 cmReference
4WD Wheelbase201 cmReference
Weight2685 to 4995 poundsReference
Front tire7.5L-15Reference
2WD Rear tire14.9-24Reference
2WD Standard tires (ag)Front: 7.5L-15. Rear: 14.9-24Reference
4WD Standard tires (ag)Front: 7.50-18. Rear: 14.9-24Reference
Length344 cmReference
Width133 cmReference
Height (steering wheel)137 cmReference
2WD Weight1217 kgReference
4WD Weight2265 kgReference
2WD Ground clearance37 cmReference
4WD Ground clearance29 cmReference
2WD Front tread108 to 148 cmReference
4WD Front tread108 to 138 cmReference
Rear tread98 to 152 cmReference
Electrical
GroundnegativeReference
Charging systemalternatorReference
Charging amps45Reference
Battery volts12Reference
Speeds
With 14.9-24 rear tires.Reference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
