Tractor · 1964Unverified
Massey Ferguson 180
Massey Ferguson 180 — Row-Crop tractor · 64 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
64 hp
Max power
40.1 kW
Weight
6685 to 6755 pounds
Hover a source tag to verify
Overview
ManufacturerMassey FergusonReference
Row-Crop tractorReference
Built in Detroit, Michigan, USAReference
Original price was $7,600 in 1975Reference
Two-wheel driveReference
Final drivesplanetaryReference
Power steeringReference
Differential mechanical disc brakesReference
Open operator station.Reference
Engine
Perkins 3.9L 4-cyl dieselReference
Perkins 3.9L 4-cyl gasolineReference
Continental 3.4L 4-cyl gasolineReference
Fuel tank109.8 LReference
Drawbar (claimed)40.3 kWReference
Drawbar (tested)40.1 kWReference
Perkins A4.236Reference
dieselReference
4-cylinder 8-valveReference
liquid-cooledReference
Displacement3.9 LReference
Bore/Stroke98 x 127 mmReference
Air cleanerpaper elementReference
Compression16:1Reference
Rated RPM2000Reference
Starter volts12Reference
Oil capacity8.0 LReference
Perkins AG4.236Reference
gasolineReference
liquid-cooled inlineReference
The Perkins AG4.236 became the gasoline engine option in 1969.Reference
Air cleanerdryReference
Compression7:1Reference
Continental G-206Reference
The G206 was used in the Massey Ferguson 180 from 1964 to 1968.Reference
Displacement3.4 LReference
Bore/Stroke97 x 114 mmReference
Compression7.1:1Reference
Power at rated engine speed47.5 kWReference
Max power40.1 kWReference
Power at rated engine speed46.5 kWReference
Max power38.7 kWReference
Transmission
12-speed partial power shiftReference
6-speed unsynchronized gearReference
TransmissionMulti-PowerReference
Typepartial power shiftReference
Gears12 forward and 4 reverseReference
Clutchdual dry discReference
Oil capacity30.3 LReference
Three gears (1-3) in two ranges (low-high) with the Multi-Power power shift.Reference
Typeunsynchronized gearReference
Gears6 forward and 2 reverseReference
PTO & Hydraulics
PTO (claimed)47.7 kWReference
PTO (tested)47.5 kWReference
Typeopen centerReference
Pressure103.4 barReference
Valves1Reference
Total flow18.2 lpmReference
Rear TypeIIReference
Rear PTOliveReference
Rear PTO Type540 (1.375)Reference
Power at rated PTO speed42.6 kWReference
Power at rated PTO speed42.3 kWReference
Dimensions
Wheelbase236 cmReference
Weight6685 to 6755 poundsReference
Front tire7.50-15Reference
Rear tire15.5-38Reference
Ag front7.50-15Reference
Ag rear15.5-38Reference
Length320 cmReference
Width185 cmReference
Height (steering wheel)207 cmReference
Gas Operating3032 kgReference
Diesel Operating3064 kgReference
Ballasted3930 kgReference
Massey Ferguson 180 attachments
front-end loaderReference
180 Serial Numbers
Location:Serial number plate mounted below the instrument panel on the 180.Reference
1965645000001Reference
1966645002423Reference
1967645004713Reference
19679A1000Reference
19689A39836Reference
19699A63158Reference
19709A87325Reference
19719A107597Reference
19729A128141Reference
19739A152025Reference
19749A179544Reference
FAQ: How to read a serial number table.Reference
Electrical
Charging systemgeneratorReference
Charging amps25Reference
Charging volts12Reference
Battery volts12Reference
Attachment overview
Massey Ferguson 245 loaderReference
Massey Ferguson 245 High Lift loaderReference
Test results
NTTL 900: diesel 12-speed 2WDReference
NTTL 1021: Perkins gasoline 12-speed 2WDReference
Diesel 12-speed 2WDMay 25 - June 9, 1965Link: Nebraska Tractor Test 900 fileReference
PTO performanceReference
Fuel use14.4 l/hourReference
Fuel use12.5 l/hourReference
Drawbar performanceReference
Fuel use14.0 l/hourReference
Gear 1-H-L used for power test.Reference
Max pull2763 kgReference
Gear 2-L-H used for pull test.Reference
Perkins gasoline 12-speed 2WDSeptember 11 - 24, 1969Link: Nebraska Tractor Test 1021 fileReference
Fuel use21.2 l/hourReference
Fuel use18.5 l/hourReference
Fuel use20.4 l/hourReference
Max pull3199 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
