Tractor · 1971Unverified

Massey Ferguson 1800

Name: Massey Ferguson 1800
Brand: Massey Ferguson

Massey Ferguson 1800 — Four-wheel Drive (4WD) tractor · 210 hp. Reference specifications; pending source verification.

The Massey Ferguson 1800 is a tractor rated at approximately 210 hp, placing it at the more powerful end of its class. It was manufactured from 1971 to 1974. The tractor features an 8-cylinder diesel liquid-cooled engine and four-wheel drive, coupled with a 12-speed gearbox. Its operating weight is listed at 7860 kg, suitable for operations spanning 600–1,500 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

210 hp

Max power

127.8 kW

Weight

7860 kg

Catalogue coverage

Variants represented

Richest spec table

95 rows

Recorded power

210 hp

Recorded weight

7860 kg

Transmissions

12-speed gear

Production years

1971-1974

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Four-wheel Drive (4WD) tractorReference

Built in Des Moines, Iowa, USAReference

Original price was $21,100 in 1974Reference

Four-wheel driveReference

Articulated power steeringReference

Hydraulic internal expanding shoe brakesReference

Cab standard. Optional heat and air-conditioning.Reference

Engine

Caterpillar 10.4L 8-cyl dieselReference

Engine156.6 kWReference

Drawbar (claimed)134.2 kWReference

Drawbar (tested)127.8 kWReference

Caterpillar 3160Reference

dieselReference

8-cylinderReference

liquid-cooled V-8Reference

Displacement10.4 LReference

Bore/Stroke114 x 127 mmReference

Power156.6 kWReference

Air cleanerdryReference

Compression16.5:1Reference

Rated RPM2800Reference

Torque642.7 NmReference

Torque RPM1400Reference

Starter volts12Reference

Oil capacity11.4 LReference

Coolant capacity45.0 LReference

Max power127.8 kWReference

Fuel TypeDieselReference

No of Cylinders8-cylinderReference

Rated engine speed2,800Reference

Engine torque at rated speed215 kgReference

Bore and stroke4.50x5.00 inchesReference

Compression ratio16.5:1Reference

Cooling systemliquid-cooled V-8Reference

Transmission

12-speed gearReference

TypegearReference

Gears12 forward and 4 reverseReference

Clutch14-inch dry discReference

Transmission TypeGearReference

forward and reverse options12 forward and 4 reverseReference

Capacities

Fuel454.2 LReference

PTO & Hydraulics

Hydraulic system56.8 LReference

Typeopen centerReference

Capacity56.8 LReference

Valves2 or 3Reference

Pump flow94.6 lpmReference

Total flow189.2 lpmReference

Steering flow94.6 lpmReference

Rear PTOoptionalReference

Rear PTO Type1000Reference

Dimensions

Wheelbase304 cmReference

Weight7860 kgReference

Front tire23.1-30Reference

Rear tire23.1-30Reference

Ag front23.1-30Reference

Ag rear23.1-30Reference

Ag front18.4-30Reference

Ag front18.4-38Reference

Ag front23.1-34Reference

Ag rear18.4-30Reference

Ag rear18.4-38Reference

Ag rear23.1-34Reference

Length533 cmReference

Height (cab)330 cmReference

Operating weight7860 kgReference

Ballasted weight9870 kgReference

Ground clearance38 cmReference

Front tread172 to 223 cmReference

Rear tread172 to 223 cmReference

1800 Serial Numbers

Location:Serial number plate on the tractor's instrument panel.Reference

19719C001007Reference

19729C001912Reference

19739C002463Reference

19749C003184Reference

FAQ: How to read a serial number table.Reference

Electrical

GroundnegativeReference

Charging systemalternatorReference

Charging amps60Reference

Batteries2Reference

Battery volts12Reference

Battery options2Reference

Test results

Diesel 12-speed 4WDNovember 4 - 17, 1971Link: Nebraska Tractor Test 1087 fileReference

Drawbar performanceReference

Fuel use48.8 l/hourReference

Max pull8360 kgReference

General

Make & ModelMassey FergusonReference

Power

Rated Power210 hpReference

PTO

Rear PTO PowerAvailableReference

Hydraulics

Hydraulics Typeopen centerReference

Remote Valves2 or 3Reference

Steering & Implements flow25 gpm (25 gpm)Reference

Dimensions & weight

Overall Height330.2 cmReference

Overall Length533.4 cmReference

Wheels & tyres

Rear wheel tread range23.1-30, 18.4-30, 18.4-38, 23.1-34, 23.1-34 inchReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
