Tractor · 2020Unverified
Massey Ferguson 1835M
Massey Ferguson 1835M — Compact Utility tractor · 28 hp. Reference specifications; pending source verification.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
28 hp
Weight
3472 to 3858 pounds
Hover a source tag to verify
Overview
ManufacturerMassey Ferguson (a part of AGCO)Reference
Compact Utility tractorReference
Original price$24,055 (2020 gear ROPS )Reference
Original price$32,774 (2020 hydrostatic Cab )Reference
Four-wheel driveReference
Power steeringReference
Wet disc brakesReference
Two-post folding ROPS. Cab optional with air-conditioning.Reference
Engine
Iseki 1.8L 3-cyl dieselReference
Fuel tank40.1 LReference
Engine27.0 kWReference
Iseki E3FHReference
turbocharged dieselReference
3-cylinderReference
liquid-cooledReference
Displacement1.8 LReference
Bore/Stroke87 x 102 mmReference
EmissionsTier IVReference
Power27.0 kWReference
Fuel systemcommon rail direct injectionReference
Air cleanerdryReference
Rated RPM2600Reference
StarterelectricReference
Starter volts12Reference
Transmission
12-speed power shuttleReference
hydrostaticReference
Typepower shuttleReference
Gears12 forward and reverseReference
Four synchronized gears in three ranges with power shuttle.Reference
TypehydrostaticReference
Gearsinfinite forward and reverse (3-range)Reference
PTO & Hydraulics
Gear PTO (claimed)20.5 kWReference
Hydro PTO (claimed)19.2 kWReference
Typeopen centerReference
Pump flow47.7 lpmReference
Steering flow26.5 lpmReference
Rear TypeIReference
Controlposition control with optional draft controlReference
Rear lift (at ends)1270 kgReference
Rear lift (at 24"/610mm)1149 kgReference
Rear PTOindependentReference
Rear PTO Type540 (1.375)Reference
Mid PTOindependentReference
Mid PTO Type1916Reference
Dimensions
Weight3472 to 3858 poundsReference
Front tire8-16Reference
Rear tire13.6-24Reference
Standard tires (ag)Front: 8-16. Rear: 13.6-24Reference
Lawn/turf front27x8.50-15Reference
Lawn/turf rear41x14.00-20Reference
Industrial front10-16.5Reference
Industrial rear14.9-24Reference
Industrial rear17.5L-24Reference
Length309 cmReference
Width171 cmReference
Height (ROPS)251 cmReference
Height (cab)231 cmReference
ROPS Weight1574 kgReference
Cab Weight1749 kgReference
Ground clearance36 cmReference
Massey Ferguson 1835M attachments
front-end loaderReference
backhoeReference
Electrical
GroundnegativeReference
Battery volts12Reference
Attachment overview
Front-end loaderReference
BackhoeReference
Massey Ferguson CB75 Backhoe
Backhoe typeMassey Ferguson CB75 BackhoeReference
Transport height193 cmReference
Digging depth233 cmReference
Reach from pivot304 cmReference
Loading height177 cmReference
Bucket Rotation174°Reference
Swing Arc175°Reference
Bucket force1397 kgReference
Dipperstick force914 kgReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
