Tractor · 2020Unverified

Massey Ferguson 1840E

Name: Massey Ferguson 1840E
Brand: Massey Ferguson

Massey Ferguson 1840E — Compact Utility tractor · 34 hp. Reference specifications; pending source verification.

The Massey Ferguson 1840E is a tractor rated at approximately 34 hp, positioning it at the lighter end of its class. Produced from 2020 to 2024, this model features a 3-cylinder turbocharged diesel liquid-cooled engine and four-wheel drive with a hydrostatic transmission. The tractor has an operating weight of 1305 kg and is suitable for operations covering up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

34 hp

Weight

1305 kg

Catalogue coverage

Variants represented

Richest spec table

46 rows

Recorded power

34 hp

Recorded weight

1305 kg

Transmissions

8-speed mechanical shuttle

Production years

2020-2024

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Compact Utility tractorReference

Four-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Wet disc brakesReference

Two-post folding ROPS.Reference

Engine

Iseki 1.8L 3-cyl dieselReference

Fuel tank37.9 LReference

Engine29.4 kWReference

IsekiReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

EmissionsTier IVReference

Power29.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed mechanical shuttleReference

hydrostaticReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)25.0 kWReference

Hydro PTO (claimed)23.5 kWReference

Typeopen centerReference

Pump flow28.8 lpmReference

Total flow43.1 lpmReference

Steering flow14.4 lpmReference

Rear TypeIReference

Rear lift (at ends)1000 kgReference

Rear lift (at 24"/610mm)724 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Weight1305 kgReference

Length295 cmReference

Width133 cmReference

Height247 cmReference

Ground clearance27 cmReference

Massey Ferguson 1840E attachments

front-end loaderReference

Electrical

GroundnegativeReference

Battery volts12Reference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
