Tractor · 2025Unverified

Massey Ferguson 1E.25

Name: Massey Ferguson 1E.25
Brand: Massey Ferguson

Massey Ferguson 1E.25 — 1E Series · 20 hp. Reference specifications; pending source verification.

The Massey Ferguson 1E.25 is a tractor with a rated power of 20 hp, categorising it as a lighter model within its class. Its engine, a 3-cylinder diesel liquid-cooled unit, is paired with a four-wheel drive and a hydrostatic transmission. Weighing 1210 kg, this tractor is suited to operations covering up to 200 acres. It was manufactured in 2025.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

20 hp

Weight

1210 kg

Catalogue coverage

Variants represented

Richest spec table

58 rows

Recorded power

20 hp

Recorded weight

1210 kg

Transmissions

8-speed mechanical shuttle

Production years

2025-2025

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS.Reference

Engine

Iseki 1.5L 3-cyl dieselReference

Fuel tank37.9 LReference

Engine17.9 kWReference

IsekiReference

dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.5 LReference

Bore/Stroke87 x 84 mmReference

Power17.9 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

8-speed mechanical shuttleReference

hydrostaticReference

Typemechanical shuttleReference

Gears8 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)15.2 kWReference

Hydro PTO (claimed)14.3 kWReference

Typeopen centerReference

Pump flow27.6 lpmReference

Steering flow13.6 lpmReference

Rear TypeIReference

Rear lift (at ends)1000 kgReference

Rear lift (at 24"/610mm)724 kgReference

Gear Rear PTOtransmissionReference

Hydro Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Weight1210 kgReference

Length295 cmReference

Width133 cmReference

Height (ROPS)247 cmReference

Ground clearance27 cmReference

Massey Ferguson 1E.25 attachments

front-end loaderReference

backhoeReference

Electrical

GroundnegativeReference

Battery volts12Reference

Attachment overview

Front-end loaderReference

BackhoeReference

Massey Ferguson BH3222 Backhoe

Backhoe typeMassey Ferguson BH3222 BackhoeReference

Transport height215 cmReference

Bucket width22 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Digging depth220 cmReference

Reach from pivot322 cmReference

Loading height187 cmReference

Bucket Rotation180°Reference

Swing Arc180°Reference

Bucket force1460 kgReference

Dipperstick force954 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
