Massey Ferguson 1M.40

Name: Massey Ferguson 1M.40
Brand: Massey Ferguson

Massey Ferguson 1M.40 — 1M Series · 30 hp. Reference specifications; pending source verification.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

30 hp

Weight

3472 to 3858 pounds

Hover a source tag to verify

Overview

ManufacturerMassey Ferguson (a part of AGCO)Reference

Compact Utility tractorReference

Four-wheel driveReference

Power steeringReference

Two-post folding ROPS. Cab optional with air-conditioning.Reference

Engine

Iseki 1.8L 3-cyl dieselReference

Fuel tank40.1 LReference

Engine29.4 kWReference

IsekiReference

turbocharged dieselReference

3-cylinderReference

liquid-cooledReference

Displacement1.8 LReference

Bore/Stroke87 x 102 mmReference

Emission controlEGR, DOC and DPFReference

Power29.4 kWReference

Rated RPM2600Reference

StarterelectricReference

Starter volts12Reference

Transmission

12-speed power shuttleReference

hydrostaticReference

Typepower shuttleReference

Gears12 forward and reverseReference

TypehydrostaticReference

Gearsinfinite forward and reverse (3-range)Reference

PTO & Hydraulics

Gear PTO (claimed)22.4 kWReference

Hydro PTO (claimed)20.8 kWReference

Typeopen centerReference

Pump flow47.7 lpmReference

Steering flow26.5 lpmReference

Rear TypeIReference

Rear lift (at ends)1270 kgReference

Rear lift (at 24"/610mm)1149 kgReference

Rear PTOindependentReference

Rear PTO Type540 (1.375)Reference

Dimensions

Weight3472 to 3858 poundsReference

Length309 cmReference

Width171 cmReference

Height (ROPS)251 cmReference

Height (cab)231 cmReference

ROPS Weight1574 kgReference

Cab Weight1749 kgReference

Ground clearance36 cmReference
