Industrial Tractor · 1961Unverified

Massey Ferguson 205

Name: Massey Ferguson 205
Brand: Massey Ferguson

Massey Ferguson 205 — Industrial tractor · 38 hp. Reference specifications; pending source verification.

The Massey Ferguson 205 is a tractor rated at approximately 38 horsepower, positioning it towards the lower end of its power class. Manufactured between 1961 and 1969, it features a 3-cylinder diesel liquid-cooled engine paired with a 2-wheel drive system and a 4-speed gearbox. The tractor is suitable for operations covering areas of up to 200 acres.

Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.

Rated power

38 hp

Catalogue coverage

Variants represented

Richest spec table

84 rows

Recorded power

38 hp

Transmissions

4-speed torque converter

Production years

1961-1969

Verified variants

1 linked source document displayed

Hover a source tag to verify

Overview

ManufacturerMassey FergusonReference

Industrial tractorReference

Two-wheel driveReference

Differential lockmechanical rearReference

Power steeringReference

Disc brakesReference

Open operator station.Reference

Variants

202gas gearReference

203diesel gearReference

204gas torque converterReference

205diesel torque converterReference

35farm tractorReference

Engine

Perkins 2.5L 3-cyl dieselReference

Engine28.3 kWReference

Perkins AD3.152Reference

dieselReference

3-cylinderReference

liquid-cooled inlineReference

Displacement2.5 LReference

Bore/Stroke91 x 127 mmReference

Power28.3 kWReference

Compression17.4:1Reference

Rated RPM2000Reference

Torque158.7 NmReference

Torque RPM1200Reference

Firing order1-2-3Reference

StarterelectricReference

Starter volts12Reference

Transmission

4-speed torque converterReference

TransmissionInstant ReverseReference

Typetorque converterReference

Gears4 forward and reverseReference

ClutchhydraulicReference

PTO & Hydraulics

Typeopen centerReference

Steering flow15.1 lpmReference

Steering press.75.8 barReference

Rear TypeIReference

Rear PTOliveReference

Rear PTO Type540 (1.375)Reference

Dimensions

Wheelbase190 cmReference

Length299 cmReference

Width167 cmReference

Height (steering wheel)135 cmReference

Ground clearance33 cmReference

Front tread167 cmReference

Rear tread121/132/142/152/162/172/182/193 cmReference

Massey Ferguson 205 attachments

front-end loaderReference

backhoeReference

205 Serial Numbers

1961659100000Reference

1962659100376Reference

1963659100712Reference

1964659100970Reference

1965659101165Reference

1966659101447Reference

19679A1001Reference

19689A213451Reference

19699A215910Reference

FAQ: How to read a serial number table.Reference

Attachment overview

Massey Ferguson 99 loaderReference

Massey Ferguson 101 loaderReference

Massey Ferguson 102 loaderReference

BackhoeReference

Massey Ferguson 185 Backhoe

Backhoe typeMassey Ferguson 185 BackhoeReference

Transport height279 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width50 cmReference

Bucket width60 cmReference

Digging depth350 cmReference

Reach from pivot530 cmReference

Loading height259 cmReference

Swing Arc180°Reference

Bucket force3288 kgReference

Massey Ferguson 220 Backhoe

Backhoe typeMassey Ferguson 220 BackhoeReference

Transport height279 cmReference

Bucket width30 cmReference

Bucket width40 cmReference

Bucket width50 cmReference

Bucket width60 cmReference

Digging depth350 cmReference

Reach from pivot530 cmReference

Loading height259 cmReference

Swing Arc200°Reference

Bucket force4037 kgReference

Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
