The Massey Ferguson 212GTX is a lawn tractor model that produces approximately 12 hp, a mid-range power output for its class. It was manufactured from 1991 to 1994. Equipped with a 1-cylinder petrol air-cooled engine and two-wheel drive, the model has an operating weight of 276 kg. It is suitable for operations spanning up to 200 acres.
Provisional listing — the headline figure is shown; full specifications are auto-generated and pending verification against published sources.
Rated power
12 hp
Weight
276 kg
Catalogue coverage
Variants represented
2
Richest spec table
54 rows
Recorded power
12 hp
Recorded weight
276 kg
Production years
1991-1994
Verified variants
0
1 linked source document displayed
Hover a source tag to verify
Overview
DistributorMassey FergusonReference
ManufacturerIngersollReference
Garden tractorReference
Two-wheel driveReference
Manual steeringReference
Band brakesReference
Open operator station.Reference
Variants
3012similar Ingersoll modelReference
Engine
12HP Kohler 476cc 1-cyl gasolineReference
Fuel tank11.4 LReference
Kohler Magnum M12AQSReference
gasolineReference
1-cylinderReference
air-cooled horizontal-shaftReference
Displacement29.07 ciReference
Bore/Stroke86 x 83 mmReference
Power (gross)8.9 kWReference
Compression6.6:1Reference
StarterelectricReference
Starter volts12Reference
Oil capacity1.9 LReference
Transmission
hydraulic driveReference
TransmissionHy-DriveReference
Typehydraulic driveReference
Gearsinfinite forward and reverseReference
PTO & Hydraulics
Typeopen centerReference
Valves2Reference
Pump flow30.3 lpmReference
Mid PTOindependentReference
ClutchelectricReference
Dimensions
Wheelbase116 cmReference
Weight276 kgReference
Front tire16x6.50-8Reference
Rear tire23x10.50-12Reference
Lawn/turf front16x6.50-8Reference
Lawn/turf rear23x10.50-12Reference
Length167 cmReference
Width93 cmReference
Height (steering wheel)102 cmReference
Height (hood)90 cmReference
Clearance (rear axle)18 cmReference
Front tread73 cmReference
Rear tread70 cmReference
Massey Ferguson 212GTX attachments
38" mid-mount mower deckReference
44" mid-mount mower deckReference
snowblowerReference
bladeReference
Electrical
GroundnegativeReference
Charging amps15Reference
Battery volts12Reference
Attachment overview
38" mid-mount mower deckReference
44" mid-mount mower deckReference
SnowblowerReference
BladeReference
Values normalized to UK metric units. Every figure is traced to at least one source; verified specs are cross-checked against two or more.
